لوحة توزيع ABB Formula
رقم الموديل: FORMULA-PLUS-3P
Ways: 4 / 8 / 12 / 18 / 24 / 36 / 42 single-pole equivalent waysVoltage: 230 V single-phase / 400 V three-phaseMain Incoming: MCB rated up to 125 ADIN Rail: TS35 (35 mm) × 3–5 rails per panel
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
لوحة توزيع ABB Formula — نظرة عامة
لوحة توزيع ABB Formula هي نظام لوحة توزيع DIN ريل معيارية للفلل السكنية والشقق والتركيبات التجارية الخفيفة، تستوعب قواطع ABB S200 MCBs وF200 RCBOs وDS200 RCDs في حاوية واحدة متسقة مصممة لشبكات التوزيع 230/400 فولت، 50 هرتز في المملكة العربية السعودية. الحاوية مصنوعة من بلاستيك ABS ذاتي الإطفاء مع تصنيف اختبار الأسلاك المتوهجة 960°C. راز الشرق الأوسط يوفر لوحات Formula مجمَّعة مسبقاً كمجموعات لوحات مستهلك جاهزة للتركيب الفوري.
المواصفات الفنية
المواصفات الكاملة لـ FORMULA-PLUS-3P
- Ways
- 4 / 8 / 12 / 18 / 24 / 36 / 42 single-pole equivalent ways
- Voltage
- 230 V single-phase / 400 V three-phase
- Main Incoming
- MCB rated up to 125 A
- DIN Rail
- TS35 (35 mm) × 3–5 rails per panel
- Enclosure Material
- Self-extinguishing ABS, glow-wire 960°C
- Enclosure Protection
- IP40 (standard door); IP54 option
- Mounting
- Flush (recessed) or surface mount
- Device Compatibility
- S200 MCB, F200 RCBO, DS200 RCD, S200M MMP
- Door
- Transparent window for circuit position visibility
- Standard
- IEC 60439-3 / IEC 60364 / SASO
المميزات والفوائد
- Full compatibility with ABB S200 MCBs, F200 RCBOs, DS200 RCDs, and S200M motor circuit breakers from a single manufacturer, providing single-source traceability, consistent Type 2 protective device coordination, and single-supplier warranty for all protective devices in the consumer unit.
- Self-extinguishing ABS enclosure with glow-wire test rating of 960°C (IEC 60695-2-11) meets IEC 60439-3 consumer unit fire safety requirements for residential and light commercial installations in Saudi Arabia, ensuring compliance with the Saudi Building Code and SASO electrical installation standards.
- Flush and surface mounting variants with identical internal DIN rail and busbar configuration allow MEP contractors to use the same consumer unit assembly on both flush and surface installations without redesigning the internal layout — reducing the number of panel assembly variants on large residential projects with mixed installation requirements.
- Transparent door window with circuit description label card allows residents, building management staff, and emergency responders to identify which MCB controls which circuit without opening the consumer unit door — an important safety feature for consumer units installed at heights or in recessed locations.
- Modular 4-to-42 way system from the smallest 4-way studio apartment consumer unit to 42-way three-phase villa consumer unit, with the same enclosure depth and DIN rail compatibility throughout the range — allowing a single standard design for all residential unit types in a multi-unit building project.
- F200 RCBO compatibility in the Formula DIN rail provides residual current protection per IEC 61008 on individual circuits without requiring a separate RCCB bank, enabling residual current protection on socket outlet and bathroom circuits as required by Saudi Building Code and SASO IEC 60364 for all new residential electrical installations.
- SASO and ECRA-compliant design documentation available for building permit submissions and ECRA electrical installation inspection approval, providing the technical specifications and product certification required by the Saudi electrical inspection authority (ECRA) for residential installation approval.
التطبيقات الصناعية
- Residential villa consumer units at ROSHN housing developments across Saudi Arabia, where MEP contractors specify ABB Formula consumer units pre-assembled with S200 MCBs for general circuits and F200 RCBOs for socket outlet and bathroom circuits to comply with Saudi Building Code RCD protection requirements.
- Apartment distribution boards in high-rise residential towers at Riyadh and Jeddah commercial districts, where each apartment floor has a Formula sub-distribution board with MCBs for apartment circuits and a main RCD, providing an economical but fully coordinated distribution system meeting ECRA inspection requirements.
- Light commercial retail unit distribution boards at NEOM Sindalah commercial marina, Red Sea Project resort retail, and Qiddiya entertainment destination retail — where the Formula's surface-mount IP40 option provides a clean, white-finished consumer unit suitable for front-of-house electrical distribution in branded retail spaces.
- Small office fit-out distribution boards at commercial business park developments in Riyadh's Olaya and King Fahd Road corridors, where electrical contractors use ABB Formula boards assembled to SASO standards for building permit approval and ECRA electrical installation certification of new office fit-outs.
- Hotel room distribution boards at branded hotel developments under Vision 2030 hospitality expansion, where each guestroom's local distribution board uses an ABB Formula with F200 RCBOs on all socket circuits meeting the international fire safety codes (NFPA 101 / IBC) required for hotel brand standard compliance.
- Saudi government housing project consumer units at Ministry of Housing developments, where standardised ABB Formula consumer unit assemblies approved by the Saudi Building Code authority are specified across all housing units in the project to achieve consistent electrical safety standards and simplify contractor procurement.
- KFUPM, KAUST, and other university campus building electrical fit-outs, where ABB Formula distribution boards are specified by the university MEP standards for consistent spares compatibility and to satisfy the SASO and ECRA certification requirements for government-owned educational facilities.
