محرك ABB M2QA منخفض الاهتزاز للمضخات IE3
رقم الموديل: M2QA132S2A
Power Range: 0.55 kW–355 kWIEC Frame Sizes: 71–315Efficiency Class: IE3 (IEC 60034-30-1 Premium Efficiency)Vibration Grade: G2.5 (ISO 1940-1) — better than standard G6.3
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
محرك ABB M2QA منخفض الاهتزاز للمضخات IE3 — نظرة عامة
محرك ABB M2QA هو محرك حثي AC منخفض الاهتزاز ومنخفض الضوضاء مُصمَّم خصيصاً لتطبيقات المضخات والنافخات حيث يجب تقليل اهتزاز العمود المنقول إلى المضخة والنظام الهيدروليكي. يُوازَن M2QA عند درجة G2.5 وفق ISO 1940-1، مما يقلل الاهتزاز المتبقي بنسبة تزيد على النصف مقارنة بالمحركات الصناعية القياسية (G6.3). يتوفر بكفاءة IE3 كمعيار (يلبي IEC 60034-30-1) ويغطي نطاق قدرات 0.55–355 كيلوواط في إطارات IEC من 71 إلى 315. راز الشرق الأوسط يُوفر محركات M2QA في أشيع أحجام الإطار وتقييمات القدرة لتطبيقات خدمات المباني في المملكة.
المواصفات الفنية
المواصفات الكاملة لـ M2QA132S2A
- Power Range
- 0.55 kW–355 kW
- IEC Frame Sizes
- 71–315
- Efficiency Class
- IE3 (IEC 60034-30-1 Premium Efficiency)
- Vibration Grade
- G2.5 (ISO 1940-1) — better than standard G6.3
- Noise Level
- Low acoustic noise (pump-optimised winding)
- Enclosure
- IP55 (standard); IP65 available
- Insulation Class
- F (155°C), thermal class B usage
- Mounting
- B3 (foot); B5 (flange); B14 (face)
- Terminal Box
- Positionable 4 × 90° positions
- Bearing Lubrication
- Grease (sealed bearings to 90 kW; regreasable above)
- Ambient Temperature
- −15 to +40°C standard; −30 to +60°C option
- Standard
- IEC 60034 / SASO IEC / CE
المميزات والفوائد
- G2.5 vibration balance grade to ISO 1940-1 — versus the standard G6.3 for general-purpose motors — reduces transmitted shaft vibration to pump couplings, impellers, and mechanical seals by more than 50%, extending pump mechanical seal MTBF at building services pump installations from the industry average of 18 months to 3+ years.
- IE3 Premium Efficiency class to IEC 60034-30-1 satisfies Saudi Energy Efficiency Program (SEEP) and NEEAP motor efficiency procurement requirements for NWC, SWCC, and SEC infrastructure projects, while providing typical energy savings of 3–5% versus IE2 motors at full-load pump operation.
- Pump-optimised winding design for continuous rated-point operation provides lower winding temperature rise and longer insulation life versus general-purpose motor windings designed for intermittent duty — directly reducing motor rewinding frequency in pump applications running 8,000+ hours per year at SWCC and NWC facilities.
- B3/B5/B14 mounting flexibility in a single motor frame covers all standard pump coupling arrangements — foot-mounted horizontal pump sets, vertical inline pump mounting, and direct end-face coupling for close-coupled pump packages — from a single motor type, simplifying procurement and spare parts inventory management.
- Terminal box repositionable in four 90-degree positions without disassembly accommodates restricted cable entry directions in confined building services plant rooms at commercial towers and hotels, avoiding costly installation re-routing that would be required with a fixed terminal box position.
- IP55 enclosure as standard provides protection against dust ingress and water jets, suitable for pump sets in wet plant rooms, pump pit installations, and outdoor pump skid arrangements without requiring special sealing or housing modifications — the standard IP protection for Saudi Arabia's pump motor installations per IEC 60034-5.
- Optional −30 to +60°C extended ambient temperature range enables operation in Saudi Arabia's unventilated outdoor pump installations where summer ambient temperatures may exceed the standard +40°C motor rating, ensuring full rated motor output and IE3 efficiency at the highest ambient temperatures without derating.
التطبيقات الصناعية
- Chilled water pump motors at five-star hotel and luxury resort HVAC systems in Riyadh, Jeddah, and Red Sea Project, where acoustic specification limits of 35 dB(A) in plant rooms below guest floors require IE3 low-vibration M2QA motors to meet the acoustic consultant's background noise criteria for JCI and Forbes Travel Guide accreditation.
- Domestic cold and hot water pressure pump sets at commercial tower and high-rise residential buildings developed by DAR AL ARKAN, Kingdom Centre, and PIF-backed development companies, where building services engineers specify low-vibration pump motors to prevent vibration transmitted through structural elements to occupied spaces.
- Hospital building services pumps (chilled water, heating, domestic, fire) at Ministry of Health and private hospital projects, where JCI accreditation requires mechanical plant acoustic compliance and the M2QA IE3 satisfies both the SEEP energy efficiency procurement mandate and the acoustic specification simultaneously.
- NWC pump station motors for domestic water supply booster pumping, where NWC procurement policy requires IE3 efficiency class on all new pump motors to comply with the Saudi Energy Efficiency Program targets — and the M2QA IE3 provides the efficiency compliance documentation required for NWC procurement approval.
- Data centre cooling pump motors at Riyadh and Jeddah hyperscale data centre facilities, where chilled water pump reliability and low vibration are critical for avoiding cooling system failures that could trigger IT equipment thermal shutdown, and where Uptime Institute Tier III/IV specifications require M2QA vibration grade documentation.
- Swimming pool and spa circulation pump motors at hotel, resort, and public leisure facility projects, where the M2QA B5 flange mounting directly mates with standard pool pump flanges and the IP55 enclosure withstands the humid, chlorine-rich pool plant room environment without corrosion damage to the motor frame or end shields.
- Irrigation pump motors at NEOM Sindalah and Red Sea Project landscaping systems, where the low vibration M2QA specification prevents vibration-induced pipeline joint fatigue failures in the extensive buried drip irrigation pipe networks, and the IE3 efficiency reduces the energy consumption of 24/7 landscape irrigation pumping in the desert environment.
