محطة ABB PASS M0 الثانوية المدمجة
رقم الموديل: PASS-M0-24
MV Voltage: 12 kV / 24 kV (to match local network)Transformer Rating: 250 / 315 / 400 / 500 / 630 / 800 / 1000 kVALV Output: 400 V AC, 3-phase + NMV Switching: SF6 RMU, 2 ring positions + 1 transformer feeder
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
محطة ABB PASS M0 الثانوية المدمجة — نظرة عامة
محطة ABB PASS M0 الثانوية المدمجة هي محطة توزيع ثانوية مجمَّعة في المصنع تُدمج وحدة حلقة رئيسية MV مُعزَّزة بغاز SF6 ومحول توزيع ولوحة توزيع LV في وحدة خارجية واحدة مكتفية بذاتها على إطار قاعدة مشترك. تصل المحطة الكاملة إلى الموقع كمجموعة واحدة مختبرة في المصنع تحتاج فقط إلى توصيل كابلات MV وكابلات الأحمال LV والتشغيل. يتراوح وقت التركيب في الموقع من يوم إلى يومين مقارنةً بأربعة إلى ثمانية أسابيع للمحطة التقليدية. تستوعب PASS M0 محولات توزيع من 250 إلى 1000 كيلوفولط أمبير. راز الشرق الأوسط ينسق توريد وتسليم وحدات ABB PASS M0 لكبار مطوري المشاريع ومقاولي البنية التحتية الكهربائية في المملكة.
المواصفات الفنية
المواصفات الكاملة لـ PASS-M0-24
- MV Voltage
- 12 kV / 24 kV (to match local network)
- Transformer Rating
- 250 / 315 / 400 / 500 / 630 / 800 / 1000 kVA
- LV Output
- 400 V AC, 3-phase + N
- MV Switching
- SF6 RMU, 2 ring positions + 1 transformer feeder
- Enclosure
- GRP (glass-reinforced polyester), IP44 outdoor
- Installation
- Factory-assembled, single-unit delivery
- Foundation
- Concrete pad (dimensions per unit size)
- Cable Entry
- Bottom cable entry, MV and LV
- LV Distribution
- MCB or MCCB outgoing feeders (number specified)
- Cooling
- Transformer ONAN (natural oil/air)
- Dimensions
- Approx. 2.8 m W × 1.6 m D × 2.2 m H (varies by rating)
- Standard
- IEC 62271-202 / SASO / SEC approval
المميزات والفوائد
- Factory-assembled and factory-tested complete substation (MV RMU + transformer + LV board) arrives at site ready for cable connection, reducing on-site installation time from four to eight weeks for a conventional kiosk substation to one to two days — the critical schedule advantage for fast-track NEOM, ROSHN, and Red Sea Project civil works.
- SF6 gas-insulated ring main unit with two ring cable positions and one transformer feeder position matches the standard SEC 13.8 kV ring main architecture, enabling direct plug-and-play connection to the existing SEC ring main network without switchgear modification.
- SASO-certified and SEC technically approved compact substation design compliant with IEC 62271-202 provides the acceptance documentation required for SEC public distribution network connection approval — a prerequisite for connecting the substation to the SEC 13.8 kV ring main in all Saudi Arabia distribution zones.
- GRP enclosure with IP44 protection and UV-resistant surface treatment withstands Saudi Arabia's direct solar irradiation (up to 1000 W/m²), 50°C ambient temperatures, and desert sandstorm abrasion — maintaining enclosure integrity and transformer cooling air circulation over the 30-year design life in outdoor installations.
- Transformer ONAN cooling with 65°C winding temperature rise rating under IEC 60076 provides design margin for operation in Saudi Arabia's 50°C ambient environment, maintaining transformer life expectancy at full rated load without forced cooling — reducing lifetime operating cost compared to ONAF transformers requiring fan maintenance.
- Compact footprint on minimal civil foundation (concrete pad only, no building required) significantly reduces civil construction cost and urban land take compared to a conventional brick or pre-cast concrete kiosk substation, enabling substation installation in residential development streetscapes with minimal visual impact.
- Modular assembly on factory-built base frame allows the PASS M0 to be repositioned or relocated using a crane if the distribution network layout changes, unlike a permanent civil kiosk substation — providing the flexibility required for phased urban development projects where substation locations are confirmed incrementally.
التطبيقات الصناعية
- Residential development distribution substations at ROSHN housing projects and Ministry of Housing residential city developments, where the PASS M0's fast installation timeline allows the electrical distribution network to keep pace with the civil construction programme and enables SEC distribution connection approval for each residential cluster as it is completed.
- NEOM urban district power distribution substations along The Line and Sindalah Island, where the compact PASS M0 footprint minimises land take in densely planned urban areas and the factory-assembly approach allows multiple substation deliveries per week to match the demanding NEOM project construction schedule.
- Red Sea Project resort development substations at Shura Island and other Red Sea Project sites, where the PASS M0 GRP enclosure's coastal corrosion resistance is essential for 30-year service life in the high-humidity salt-air marine environment, and the compact design fits the resort landscaping aesthetic requirements.
- Industrial estate incoming substations at MODON, SIDF, and King Salman Energy Park (SPARK) industrial lot developments, where factory developers require fast power connection for fit-out and production start, and the PASS M0 enables SEC-approved substation commissioning within weeks of lot handover.
- Temporary construction power substations at major infrastructure projects (NEOM, KAIA airport expansion, Riyadh Metro extension), where the PASS M0's relocatable design allows substations to be moved to new construction fronts as the project progresses, reducing the capital cost of temporary construction power infrastructure.
- Commercial development master-planned infrastructure substations at mixed-use developments in Riyadh, Jeddah, and Dammam, where SEC network connection requires ring main unit substations meeting IEC 62271-202 that the PASS M0 delivers with SEC approval documentation, enabling SEC connection approval without custom engineering.
- Telecommunication tower and mobile base station power supply substations for STC, Zain, and Mobily 5G network expansion, where the PASS M0 provides the dedicated MV-to-LV substation required for high-power 5G tower equipment in areas where the existing LV distribution capacity is insufficient for the additional telecom loads.
