منتج شنايدر METSEPM8213

المواصفات الفنية

المواصفات الكاملة لـ PM8213

Range

PowerLogic

Product name

PowerLogic PM8000

Product or component type

Power meter

Device short name

PM8213

model type

Standard

Device application

WAGES metering; Power monitoring

Type of measurement

Current; Voltage; Frequency; Active and reactive power total; Apparent power total; Power factor total; Active and reactive power per phase, rms; Apparent power per phase, rms; Power factor per phase, rms

supply voltage

20...60 V DC +/- 10 %

Network frequency

60 Hz; 50 Hz

In rated current

1 A; 10 A; 5 A

Poles description

3P; 1P + N; 3P + N

Power consumption in W

18 W

Display type

Without display

Sampling rate

256 samples/cycle

Measurement current

50…10000 mA

Analogue input type

Voltage (impedance 5 MOhm); Current (impedance 0.3 mOhm)
