وحدة توزيع الطاقة APC Rack PDU مقاسة/مُتحكم بها 1–2 وحدة
رقم الموديل: AP7853
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
وحدة توزيع الطاقة APC Rack PDU مقاسة/مُتحكم بها 1–2 وحدة — نظرة عامة
وحدة توزيع الطاقة APC Rack PDU توفر توزيع الطاقة المراقبة والمقيسة والمتحكم بها على مستوى الرف، مما يُمكّن إدارة الطاقة عن بُعد لكل منفذ في غرف الخوادم.
تُستخدم على نطاق واسع في مراكز البيانات ومراكز التحلية وغرف الخوادم الحكومية في المملكة العربية السعودية.
المواصفات الفنية
المواصفات الكاملة لـ AP7853
- Form Factor
- 0U vertical or 1U horizontal
- Rated Current
- 16 A or 32 A (model dependent)
- Outlets
- 24 × IEC C13 + 6 × IEC C19 (typical)
- Phases
- 1-phase or 3-phase
- Switching
- Per-outlet individual switching
- Communication
- SNMP, HTTP/HTTPS, Modbus TCP
- Monitoring
- Inlet, outlet current, voltage, energy
- Standard
- IEC 60309
المميزات والفوائد
- Individual outlet switching enables remote power cycling of locked-up servers and scheduled outlet management, eliminating the need for physical site visits to reboot failed equipment in unmanned server rooms.
- Per-outlet current, voltage, and energy metering feeds real-time rack-level power data to EcoStruxure IT, enabling accurate PUE calculation and tenant billing in colocation facilities.
- 0U vertical mount form factor preserves all 42U–48U rack space for IT equipment, with zero rack unit consumption versus 1U horizontal PDUs — important in high-density, high-cost colocation rack deployments.
- Embedded network management card with SNMP v1/v2c/v3, HTTP/HTTPS, and Modbus TCP provides secure, multi-protocol remote management without an external NMC2 card or separate controller.
- Phase load balancing across three-phase PDU outlets helps data centre operators keep three-phase input currents within 5% of each other, satisfying SEC supply authority power quality requirements.
- Configurable current thresholds with email and SNMP trap alerts provide advance warning of overloaded branch circuits before MCB tripping causes unplanned IT equipment outages.
- Daisy-chain network port enables multiple PDUs in a rack to share a single network connection, reducing IP address consumption and switch port requirements in large multi-rack deployments.
التطبيقات الصناعية
- Colocation data centre rack power metering for tenant billing at STC, Mobily, and international hyperscale facilities entering Saudi Arabia, where per-outlet kWh data feeds automated billing systems.
- Enterprise server room power management at Saudi banking institutions, where remote outlet switching enables after-hours server power cycling without calling in on-site staff.
- ARAMCO IT infrastructure rack power monitoring at Dhahran data centre, where outlet-level energy data supports corporate sustainability reporting and energy efficiency improvement programmes.
- NEOM smart city edge compute node power distribution, where 0U PDUs distribute UPS-backed power to rack-mounted edge servers and networking equipment in space-constrained node cabinets.
- University HPC cluster power distribution at KAUST and KFUPM, where three-phase PDUs balance load across the high-density GPU server racks used for AI and simulation workloads.
- Government ministry data centre power monitoring under the Yesser national cloud programme, where rack-level metering data feeds the National Data Center energy consumption reporting platform.
- Telecom equipment room power distribution for STC and Zain 5G core network nodes, where switched PDUs enable remote equipment reset during network fault management procedures.
