فولتميتر وأميتر اللوحة Schneider Acti9 IVV8
رقم الموديل: A9C15900
Measurement: Phase-to-neutral voltage (0–500 V) and current (0–63 A)Resolution: 3-digit displayConnection: Direct Acti9 busbar comb + iCT CT inputWidth: 1 DIN module
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
فولتميتر وأميتر اللوحة Schneider Acti9 IVV8 — نظرة عامة
فولتميتر وأميتر IVV8 هو جهاز قياس رقمي مثبت على قضيب DIN يوفر قياساً مستمراً للجهد والتيار في لوحات التوزيع Acti9 دون أسلاك خارجية.
يُستخدم في لوحات توزيع أرامكو ومشاريع NEOM والمباني التجارية في المملكة العربية السعودية.
المواصفات الفنية
المواصفات الكاملة لـ A9C15900
- Measurement
- Phase-to-neutral voltage (0–500 V) and current (0–63 A)
- Resolution
- 3-digit display
- Connection
- Direct Acti9 busbar comb + iCT CT input
- Width
- 1 DIN module
- Display
- LCD digital
- Phase Selection
- Built-in rotary switch
- Auxiliary Supply
- Self-powered from measured circuit
- Standard
- IEC 61557
المميزات والفوائد
- Direct Acti9 DIN busbar comb connection eliminates external voltage tap wiring, providing installed voltage and current measurement at the panel for the equivalent cost of an MCB.
- 1 DIN module width and snap-in installation integrate the IVV8 into any Acti9 distribution board position without modification to the board's busbar or DIN rail layout.
- Built-in rotary phase selector allows a single IVV8 to read all three phases and neutral voltage and any of the three phase currents, covering the complete supply status with one instrument.
- Self-powered from the measured circuit eliminates auxiliary power wiring, keeping the IVV8 installation to a single DIN rail snap-in and CT clip-on connection.
- Permanent display provides continuous supply voltage and load current visibility for facility technicians during inspection rounds, eliminating reliance on handheld multimeters for routine checks.
- 0–500 V voltage range and 0–63 A current range cover all Saudi Arabia's LV distribution voltages (230 V single-phase, 400 V three-phase) and standard MCB current ratings up to the 63 A Acti9 maximum.
- IEC 61557 measurement instrument standard compliance ensures measurement accuracy suitable for voltage quality assessment and current imbalance detection in Saudi facility electrical maintenance.
التطبيقات الصناعية
- ARAMCO facility expansion distribution board voltage and current monitoring, where IVV8 provides local electrical status to operations technicians without requiring SCADA terminal access.
- NWC pump station control panel supply monitoring, where IVV8 allows technicians to verify supply voltage and pump motor current at the panel during routine site visits.
- NEOM The Line residential and commercial floor distribution board local status indication, where IVV8 provides building operations teams with immediate electrical status without network infrastructure.
- Commercial building tenant sub-distribution board monitoring, where IVV8 allows facilities management technicians to confirm supply and load conditions at each floor panel during maintenance rounds.
- Hospital wing distribution board status monitoring under Ministry of Health technical specifications, where local voltage indication at each sub-panel supports rapid fault response in critical electrical zones.
- Industrial estate tenant factory distribution board monitoring, where IVV8 provides the tenant's electrical maintenance team with supply voltage verification for machinery troubleshooting.
- Solar PV AC inverter output distribution board monitoring, where IVV8 provides local inverter output voltage and current indication at the DC-AC inverter output panel for daily performance check.
