جهاز البدء الناعم شنايدر Altistart 22
رقم الموديل: ATS22D17Q
Current Range: 6–1200 AVoltage: 208–690 V ACControl: Progressive torque rampBypass Contactor: Built-in (up to ATS22D88)
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
جهاز البدء الناعم شنايدر Altistart 22 — نظرة عامة
جهاز البدء الناعم Altistart 22 من شنايدر إلكتريك يغطي 6 إلى 1200 أمبير مع تحكم تدريجي في العزم لبدء ناعم وإيقاف ناعم للمحركات. يتضمن كونتاكتور تجاوز مدمج وحماية شاملة للمحرك مع Modbus RTU مدمج. يُستخدم في محطات ضخ المياه ومنشآت التبريد والمرافق الصناعية في المملكة العربية السعودية، وتوفره راز الشرق الأوسط من مخزون محلي.
المواصفات الفنية
المواصفات الكاملة لـ ATS22D17Q
- Current Range
- 6–1200 A
- Voltage
- 208–690 V AC
- Control
- Progressive torque ramp
- Bypass Contactor
- Built-in (up to ATS22D88)
- Communication
- Modbus RTU RS485 built-in
- Protection
- Thermal OL, phase loss, phase imbalance, thermistor
- Ambient Temperature
- -25 to +60°C (operating)
- Starting Modes
- Voltage ramp / torque control
- Stop Modes
- Free wheel / deceleration ramp
المميزات والفوائد
- Progressive torque control starting mode adjusts voltage to maintain constant torque profile during acceleration, providing smoother starting on high-inertia loads than basic voltage-ramp softstarters and eliminating current peaks that cause supply voltage flicker.
- Built-in bypass contactor eliminates continuous thyristor power dissipation during running, improving softstarter efficiency and extending thyristor service life compared to designs without integrated bypass.
- Electronic thermal overload with motor class selection (class 5 to 30) replaces the separate overload relay in standard motor starting panels, reducing component count and simplifying panel wiring.
- Modbus RTU communication built-in enables remote starting current monitoring, motor thermal state reporting, and fault history access from PLC or SCADA systems without additional communication modules.
- Deceleration ramp (pump stop) function gradually reduces motor speed before stopping, eliminating water hammer in pump installations and reducing mechanical stress on pipeline fittings and check valves.
- Thermistor input for direct PTC or NTC motor temperature sensor monitoring provides real-time winding temperature protection for high-duty motors operating in high-ambient Saudi environments.
- 50°C continuous ambient operating temperature without derating covers the peak summer conditions in Saudi Arabia's industrial plant rooms, outdoor utility cubicles, and mechanical equipment rooms.
التطبيقات الصناعية
- Large centrifugal pump starting at NWC municipal water booster stations, where deceleration ramp eliminates water hammer on pump shutdown in long distribution mains serving Riyadh's residential districts.
- Compressor motor starting at industrial facilities in MODON zones across Riyadh, Jeddah, and Dammam, where reduced starting current eliminates transformer overload and supply voltage flicker on shared distribution circuits.
- HVAC chilled water and condenser water pump starting in commercial buildings and district cooling plants, where progressive torque control eliminates pressure surge and mechanical coupling stress during motor acceleration.
- Conveyor belt motor starting at cement and aggregate processing plants, where smooth torque ramp prevents belt splice failure and extends belt service life compared to DOL starting.
- Fan motor starting in large industrial ventilation systems and dust collection plant, where high-inertia fan starting with controlled torque profile prevents motor current exceeding 350% of rated value.
- Desalination plant seawater pump and brine reject pump starting at SWCC facilities, where deceleration ramp prevents water hammer on the long seawater intake and brine disposal pipelines.
- Refrigeration compressor and screw compressor starting in food cold store and industrial refrigeration facilities, where controlled starting torque protects the compressor's positive displacement mechanism from DOL torque spikes.
