محرك الآلات شنايدر Altivar 340
رقم الموديل: ATV340U40N4E
Voltage Range: 380–480 V AC three-phasePower Range: 0.37–90 kWControl Method: Sensorless flux vector / closed-loop vectorSafety Functions: STO/SS1/SS2/SOS/SLS/SDI/SMS — SIL 3 / PLe
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
محرك الآلات شنايدر Altivar 340 — نظرة عامة
محرك Altivar 340 من شنايدر إلكتريك يغطي 0.37 إلى 90 كيلوواط وهو مصمم لتطبيقات الآلات عالية الأداء مع CANopen مدمج ووظائف سلامة متقدمة تصل إلى SIL 3. يدعم محركات الحث غير المتزامنة ومحركات المغناطيس الدائم. يُستخدم في المصانع الكيماوية والدوائية في المملكة العربية السعودية، وتوفره راز الشرق الأوسط مع دعم هندسي متكامل.
المواصفات الفنية
المواصفات الكاملة لـ ATV340U40N4E
- Voltage Range
- 380–480 V AC three-phase
- Power Range
- 0.37–90 kW
- Control Method
- Sensorless flux vector / closed-loop vector
- Safety Functions
- STO/SS1/SS2/SOS/SLS/SDI/SMS — SIL 3 / PLe
- Communication
- CANopen + Modbus built-in
- Motor Types
- Asynchronous + synchronous PM
- Speed Accuracy
- ±0.01% with encoder
- Starting Torque
- 200%
- Harmonic Filter
- AFE option <5% THDi
المميزات والفوائد
- Safety function set including STO, SS1, SS2, SOS, SLS, SDI, and SMS certified to SIL 3 / PLe satisfies the most stringent machinery safety requirements without a dedicated safety PLC, reducing system cost and complexity.
- Synchronous permanent magnet motor support alongside standard asynchronous motor control allows machine designers to adopt IE4-class PM motors for superior energy efficiency without changing the drive platform.
- Sensorless flux vector control delivering 200% starting torque with ±0.01% speed regulation (encoder) replaces traditional servo drives on constant-torque machine axes at significantly lower cost.
- EcoStruxure Machine Expert integration enables single-tool programming of Modicon PLC logic and ATV340 drive parameters, reducing engineering time for complex multi-axis machine projects.
- Active front end option reduces supply harmonics below 5% THDi, meeting IEEE 519 requirements for installation on sensitive electrical networks in petrochemical complexes and data centre facilities.
- Graphical display with motor control tuning oscilloscope function allows in-situ current and speed waveform analysis without external instrumentation, speeding up machine commissioning and fault diagnosis.
- Parameter cloning via memory card or USB enables rapid drive replacement during production without re-commissioning, minimising unplanned downtime at remote or continuous-process Saudi manufacturing sites.
التطبيقات الصناعية
- Precision conveyor and indexing drives in pharmaceutical packaging lines at SABIC-approved manufacturing facilities in Jubail, where SIL 3 safety certification satisfies process safety management audit requirements.
- Machine tool spindle and axis drives at NEOM's advanced manufacturing hub, where PM motor support and encoder feedback achieve CNC-class speed accuracy at a fraction of dedicated servo drive cost.
- Winding and unwinding tension control drives in flexible packaging and laminating machinery, where the drive's closed-loop torque mode maintains constant web tension during acceleration and deceleration.
- Extruder screw drive and die temperature zone control drives in polymer and rubber processing at Jubail petrochemical plants, where active front end reduces harmonic loading on sensitive plant power systems.
- Centrifuge and separation equipment drives in petrochemical laboratories and production facilities, where the full safety function set enables safe-speed monitoring during door interlock cycles.
- Robotic cell auxiliary drives and material handling conveyors at Saudi defence and aerospace manufacturing facilities in Riyadh, where EcoStruxure integration enables unified machine control architecture.
- Paper and corrugated packaging machine drives at Saudi paper manufacturers, where the 90 kW top rating covers main section drives while maintaining consistent motion quality across the machine train.
مورد معتمد في المملكة العربية السعودية
احصل على عرض سعر لـ محرك الآلات شنايدر Altivar 340
نرد خلال 4 ساعات. أرسل رقم الموديل ATV340U40N4E للحصول على سعر تنافسي مع التسليم في أنحاء المملكة العربية السعودية والخليج.
أسئلة شائعة حول محرك الآلات شنايدر Altivar 340
أكثر الأسئلة شيوعاً من العملاء في المملكة العربية السعودية
