محرك متعدد الأغراض شنايدر Altivar 600
رقم الموديل: ATV600C11N4
Voltage Range: 380–480 V AC three-phasePower Range: 0.75–630 kWControl: Scalar / Sensorless vector / Flux vectorEnclosure: IP21 / IP55
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
محرك متعدد الأغراض شنايدر Altivar 600 — نظرة عامة
محرك Altivar 600 من شنايدر إلكتريك يغطي 0.75 إلى 630 كيلوواط وهو محرك متعدد الأغراض مع خيار IP55 مدمج واتصال EcoStruxure للمراقبة الذكية. يدعم محركات التحريض والمتزامنة ويوفر كفاءة محسنة مع حزم SyRM. يُستخدم على نطاق واسع في المملكة العربية السعودية في عمليات أرامكو وتعدين معادن، وتوفره راز الشرق الأوسط بمخزون محلي.
المواصفات الفنية
المواصفات الكاملة لـ ATV600C11N4
- Voltage Range
- 380–480 V AC three-phase
- Power Range
- 0.75–630 kW
- Control
- Scalar / Sensorless vector / Flux vector
- Enclosure
- IP21 / IP55
- Communication
- Modbus TCP + EtherNet/IP built-in
- Motor Types
- Asynchronous, SyRM, PM
- EcoStruxure
- Built-in IIoT connectivity
- Ambient Temperature
- -15 to +50°C
- Load Sharing
- Built-in master/follower
- EMC Filter
- Built-in
المميزات والفوائد
- IP55 enclosure option on frames up to 90 kW ships as standard (no add-on kit required), enabling direct outdoor or dusty environment installation without an additional weatherproof enclosure cabinet.
- EcoStruxure IIoT connectivity built-in provides live drive health data — load, temperature, run hours, fault history — to Schneider Electric's cloud monitoring platform for predictive maintenance scheduling.
- Synchronous reluctance motor (SyRM) support enables up to 10% better system efficiency versus standard IE3 motor and drive packages when paired with Schneider Electric's IE4 SyRM motor range.
- Built-in Modbus TCP and EtherNet/IP communication ports allow simultaneous SCADA connection and EcoStruxure cloud data upload without additional communication cards or port conflicts.
- Master/follower load sharing function synchronises multiple ATV600 drives on shared mechanical loads such as long conveyors and overhead crane hoists without external synchronisation controllers.
- Embedded QR code on the drive keypad links to online documentation, parameter lists, and service resources, enabling field technicians to access current information without printed manuals.
- Auto-tuning routine for SyRM and PM motors characterises motor parameters in under two minutes during commissioning, optimising vector control performance without manual calculation.
التطبيقات الصناعية
- Utility pump and fan drives at Saudi Aramco production facilities in the Eastern Province, where IP55 protection allows direct installation in outdoor utility areas without additional weatherproof cabinets.
- Mineral conveyor and crusher drives at Ma'aden phosphate and gold mining operations in northern Saudi Arabia, where master/follower load sharing maintains tension balance across multi-drive long conveyors.
- HVAC chilled water pump and AHU fan drives in large commercial and industrial buildings across Riyadh, Jeddah, and Dammam, where EcoStruxure connectivity enables energy performance reporting for LEED certification.
- Water injection and transfer pump drives in SABIC petrochemical process plants at Jubail, where IP55 protection and robust sensorless vector control provide reliable 24/7 operation in outdoor pump stations.
- Desalination pre-treatment pump drives at SWCC and NWC water infrastructure projects, where the drive's broad power range allows standardisation on a single product family from small dosing pumps to large transfer pumps.
- Compressor auxiliary and cooling fan drives at SEC power generation facilities, where EcoStruxure monitoring provides advance warning of drive thermal degradation in high-ambient plant rooms.
- Cement plant raw mill, kiln drive, and cooler fan applications at Saudi cement manufacturers in Riyadh and Jizan regions, where high ambient temperature tolerance and dustproof IP55 construction are mandatory requirements.
