محرك HVAC شنايدر Altivar 61 (الجيل السابق)
رقم الموديل: ATV61HD11N4
Voltage Range: 380–480 V AC three-phasePower Range: 0.75–800 kWHVAC Macros: AHU, pump, fan built-inCommunication: Modbus RTU built-in
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
محرك HVAC شنايدر Altivar 61 (الجيل السابق) — نظرة عامة
محرك Altivar 61 من شنايدر إلكتريك هو محرك HVAC من الجيل السابق يغطي 0.75 إلى 800 كيلوواط ولا يزال واسع الانتشار في المملكة العربية السعودية في المباني التجارية والمستشفيات والفنادق المشيدة بين 2005 و2020. تحتفظ راز الشرق الأوسط بمخزون من قطع الغيار ووحدات الاستبدال لدعم هذه القاعدة المنتشرة على نطاق واسع.
المواصفات الفنية
المواصفات الكاملة لـ ATV61HD11N4
- Voltage Range
- 380–480 V AC three-phase
- Power Range
- 0.75–800 kW
- HVAC Macros
- AHU, pump, fan built-in
- Communication
- Modbus RTU built-in
- Optional
- PROFIBUS, BACnet, Modbus TCP
- Enclosure
- IP21 (IP54 kit available)
- Ambient Temperature
- -10 to +50°C
- Sleep/Wake
- Built-in
- PID Controller
- Built-in with auto-tuning
المميزات والفوائد
- Purpose-built HVAC macros for AHU, pump, and fan applications reduce commissioning time for building services drives, with pre-loaded motor and application parameters covering the most common HVAC duty configurations.
- Built-in Modbus RTU communication with optional BACnet, PROFIBUS, and Ethernet Modbus TCP cards enables integration into virtually every BMS platform encountered in Saudi Arabia's diverse building stock.
- Proven reliability record across Saudi Arabia's extreme temperature cycle (up to +50°C summer ambient) establishes the ATV61 as a reference-quality product for facilities management contracts where MTBF is contractually specified.
- Graphical remote display option with extended cable allows the HMI to be located on the panel door or above a suspended ceiling while the drive sits in a plant room, simplifying access for operator monitoring.
- Sleep/wake function with minimum frequency hold prevents unnecessary motor and drive wear during low-demand periods in commercial buildings with variable occupancy and seasonal HVAC load profiles.
- Phase loss detection and motor thermal model protection guard motors against the single-phasing and overload conditions that occur during normal building services operation, reducing motor repair costs.
- Parameter storage and cloning capability enables failed drive replacement with full parameter restoration in under 30 minutes, minimising HVAC plant downtime in occupied buildings during emergency repairs.
التطبيقات الصناعية
- AHU fan and chilled water pump drive replacement and maintenance at Ministry of Health hospitals across Saudi Arabia's 13 regions, where ATV61 installed base continuity is critical to patient care infrastructure.
- Commercial tower HVAC drive maintenance at Riyadh's King Abdullah Financial District and Jeddah's waterfront towers, where facilities management contracts require like-for-like ATV61 replacement capability.
- Hotel HVAC plant maintenance at Makkah's Abraj Al-Bait complex and Madinah's hospitality district, where year-round high occupancy during Hajj and Umrah seasons demands maximum HVAC system availability.
- Government ministry and institutional building HVAC maintenance in Riyadh's diplomatic quarter and government complex, where extended maintenance contracts require local spare part availability.
- University campus HVAC system maintenance at King Abdulaziz University Jeddah and King Fahd University Dhahran, where campus engineering teams maintain large ATV61 populations across multiple buildings.
- Industrial facility HVAC and process fan maintenance at MODON industrial estate tenants, where process continuity requirements demand rapid ATV61 replacement from local stock.
- Retrofit upgrade projects from ATV61 to ATV630 where facilities managers invest in the next-generation drive during planned HVAC refurbishment, benefiting from Razz Middle East's experience with both product generations.
