محرك المياه ومعالجة الصرف شنايدر Altivar 650
رقم الموديل: ATV650D11N4
Voltage Range: 380–480 V AC three-phasePower Range: 0.75–800 kWPump Functions: Anti-cavitation, dry-run, de-clog, pipe-fill, cascade (6 pumps)Predictive Maintenance: Pump curve monitoring
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
محرك المياه ومعالجة الصرف شنايدر Altivar 650 — نظرة عامة
محرك Altivar 650 من شنايدر إلكتريك مخصص لتطبيقات ضخ المياه ومعالجة الصرف الصحي يغطي 0.75 إلى 800 كيلوواط. يتضمن كشف التجويف والتشغيل الجاف ودورة إلغاء الانسداد وتتالي مضخات متعددة حتى 6 مضخات. يُستخدم في منشآت SWCC وNWC وشبكات المياه في المملكة العربية السعودية، وتوفره راز الشرق الأوسط مع وثائق تشغيل متوافقة مع NWC.
المواصفات الفنية
المواصفات الكاملة لـ ATV650D11N4
- Voltage Range
- 380–480 V AC three-phase
- Power Range
- 0.75–800 kW
- Pump Functions
- Anti-cavitation, dry-run, de-clog, pipe-fill, cascade (6 pumps)
- Predictive Maintenance
- Pump curve monitoring
- Communication
- Modbus TCP + EtherNet/IP
- Enclosure
- IP21 / IP55
- Ambient Temperature
- -15 to +50°C
- Sleep/Wake
- Built-in with minimum speed hold
المميزات والفوائد
- Pump predictive maintenance function monitors hydraulic efficiency against stored pump curve, generating maintenance alerts for impeller wear, bearing deterioration, or blockage before pump failure occurs.
- Anti-cavitation detection reduces pump speed automatically when inlet pressure drops below the cavitation threshold, preventing impeller damage without external low-pressure switches or manual intervention.
- Pump de-clogging cycle periodically reverses pump rotation briefly to clear fibrous debris from impellers in sewage and sludge pumping applications, reducing pump pull-out and manual cleaning frequency.
- Pipe-fill ramp function pressurises empty pipework at controlled velocity, preventing water hammer in newly commissioned or recommissioned long transmission mains and distribution systems.
- Multi-pump cascade manages up to 6 pumps automatically without a separate pump controller, sequencing lag pumps by run-hour equalisation to balance wear across the installed pump bank.
- Dry-run protection trips the drive before mechanical seal and bearing damage from air-locked operation, critical for remote unmanned booster stations where delayed response to alarms is common.
- Modbus TCP and EtherNet/IP communication enables full integration into NWC and ARAMCO SCADA platforms, providing live pump station flow, pressure, and drive health data to central control rooms.
التطبيقات الصناعية
- NWC municipal water distribution booster stations across Riyadh, Jeddah, and Dammam serving the Kingdom's rapidly growing urban residential developments under Vision 2030 housing programmes.
- SWCC desalination plant high-pressure and transfer pump drives at Jubail, Yanbu, and coastal Red Sea facilities, where continuous 24/7 operation in corrosive seawater environments demands maximum drive reliability.
- Municipal wastewater lift station drives for Riyadh's northern and eastern expansion zones, where pump de-clogging and dry-run protection reduce emergency call-outs to remote unmanned installations.
- ARAMCO utility water injection and cooling water pump drives in Eastern Province production facilities, where pump curve monitoring identifies performance degradation before it impacts process cooling capacity.
- Centre-pivot irrigation pump drives at agricultural projects in Qassim and Al-Ahsa, where sleep/wake energy saving and cascade control match pumping rate to evapotranspiration demand.
- Industrial effluent treatment and process water pump drives at SABIC and Ma'aden manufacturing complexes in Jubail and Al Khali, where precise flow control supports water balance management.
- NWC-funded rural water supply booster stations serving Vision 2030 infrastructure development in Tabuk, Jizan, Hail, and Al Qassim regions, where remote SCADA integration reduces operational staffing costs.
