شاحن EVlink Smart Wallbox من Schneider بقدرة 7.4–22 كيلوواط
رقم الموديل: EVW2S22P04K
Charging Power: 7.4 kW (1-phase) or 22 kW (3-phase)Connector: IEC 62196-2 Type 2, dual socket or tetheredSessions: 2 simultaneousEnergy Meter: MID-certified kWh
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
شاحن EVlink Smart Wallbox من Schneider بقدرة 7.4–22 كيلوواط — نظرة عامة
شاحن EVlink Smart Wallbox هو محطة شحن سيارات كهربائية احترافية بقدرة 22 كيلوواط مع إدارة أحمال ذكية وعداد طاقة مدمج وبروتوكول OCPP لإدارة نقاط الشحن.
يُستخدم في بيئات العمل والتجزئة والمواقف التجارية في المملكة العربية السعودية.
المواصفات الفنية
المواصفات الكاملة لـ EVW2S22P04K
- Charging Power
- 7.4 kW (1-phase) or 22 kW (3-phase)
- Connector
- IEC 62196-2 Type 2, dual socket or tethered
- Sessions
- 2 simultaneous
- Energy Meter
- MID-certified kWh
- Communication
- OCPP 1.6, Ethernet, Wi-Fi, 4G
- Enclosure
- IP54, IK10
- Access
- RFID ISO 14443A
- Load Management
- Dynamic current regulation
المميزات والفوائد
- Dynamic load management monitors available site electrical capacity in real time and adjusts EV charging current to prevent main breaker overload during peak HVAC and process load coincidence.
- Dual socket or dual tethered cable design provides two simultaneous EV charging sessions from a single installation, halving per-session infrastructure cost versus two separate single-socket units.
- MID-certified integrated energy meter enables legally admissible kWh billing for OCPP-connected charging networks, supporting employee EV reimbursement programmes and public pay-per-kWh charging.
- OCPP 1.6 protocol integration connects to any CPMS platform for remote monitoring, roaming authentication, payment processing, and utilisation reporting across multi-site charging networks.
- IK10 vandal resistance and IP54 environmental sealing maintain operability in outdoor car park environments exposed to sand, humidity, and physical impact from vehicle manoeuvring.
- ISO 14443A RFID reader supports contactless card, key fob, and NFC smartphone authentication — enabling access control integration with existing building access control systems.
- 4G cellular communication option eliminates Ethernet infrastructure requirements at outdoor car park locations, enabling rapid deployment without civil works for data cabling.
التطبيقات الصناعية
- Saudi Aramco and SABIC employee car park EV charging at Dhahran and Jubail facilities, where Smart Wallbox dynamic load management prevents overloading of car park substation supply circuits during peak shift hours.
- NEOM commercial district structured car park EV charging, where OCPP connectivity integrates with NEOM's smart city mobility platform for utilisation analytics and resident billing.
- Red Sea Global hospitality venue guest parking EV charging at AMAALA and Red Sea resort complexes, where dual-socket units maximise charging positions per installation in premium guest parking areas.
- Riyadh Metro park-and-ride facility EV charging infrastructure, where OCPP-managed Smart Wallboxes integrate with SAPTCO transport payment systems for combined transit and charging billing.
- MODON industrial estate visitor and employee car park EV charging at Riyadh and Dammam industrial cities, satisfying new MODON development standard EV charging requirements for tenant occupancy.
- Saudi bank and financial institution headquarters EV fleet charging at corporate car parks, where MID metering enables accurate cost allocation between bank fleet and employee reimbursement accounts.
- Airport ground transport EV charging at King Khalid International Airport and King Abdulaziz International Airport, where OCPP management enables GACA-compliant revenue metering for airport concession contracts.
