محرك سيرفو Schneider Lexium 62 المتقدم بـ EtherCAT
رقم الموديل: LXM62DU60A21000
Power Range: Up to 15 kW per axisEncoder Resolution: 20-bit (1,048,576 ppr)Cycle Time: 250 µs minimumBus: EtherCAT with distributed clock sync
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
محرك سيرفو Schneider Lexium 62 المتقدم بـ EtherCAT — نظرة عامة
محرك Lexium 62 هو محرك سيرفو متقدم بتقنية EtherCAT الأصلية مصمم لأنظمة الحركة المتزامنة متعددة المحاور في آلات التعبئة المتقدمة والروبوتات وتطبيقات الطباعة.
يُستخدم في خطوط الإنتاج عالية السرعة لشركات الألبان والغذاء والتغليف في المملكة العربية السعودية.
المواصفات الفنية
المواصفات الكاملة لـ LXM62DU60A21000
- Power Range
- Up to 15 kW per axis
- Encoder Resolution
- 20-bit (1,048,576 ppr)
- Cycle Time
- 250 µs minimum
- Bus
- EtherCAT with distributed clock sync
- Safety
- STO/SS1/SS2/SOS/SLS, SIL 3 / PLe
- Dual-Axis Option
- 2 axes per drive unit
- Common DC Bus
- Yes (energy sharing)
- Standard
- IEC 61800-5-2, EN ISO 13849-1
المميزات والفوائد
- EtherCAT distributed clock synchronisation achieves inter-axis synchronisation better than 1 µs, enabling electronic gearing and flying shear applications in high-speed packaging and printing machinery.
- 20-bit encoder resolution provides 1,048,576 counts per revolution, delivering sub-arcsecond position accuracy for precision cut-to-length, registration, and indexing axes in converting machinery.
- Dual-axis option controls two servo motor axes from a single drive unit with shared DC bus, halving panel space requirements and enabling direct energy sharing between braking and accelerating axes.
- SIL 3 / PLe integrated safety functions — STO, SS1, SS2, SOS, SLS — cover the highest machinery safety integrity level requirements without external safety hardware or PLCs.
- 250 µs EtherCAT cycle time supports real-time current, speed, and position loop closure across 16+ axes on a single machine bus, enabling the tight multi-axis coordination of advanced robotic and packaging systems.
- EcoStruxure Machine integration with Modicon M262 machine controller provides a complete, pre-validated single-platform solution reducing machine builder integration risk and commissioning time.
- Regenerative braking energy sharing via common DC bus returns motor deceleration energy to other accelerating axes rather than dissipating it as heat, reducing energy consumption by up to 15% in cyclic multi-axis applications.
التطبيقات الصناعية
- High-speed form-fill-seal packaging line servo axes at Almarai, Sadafco, and Savola Group food manufacturing facilities in Riyadh and Jeddah, where Lexium 62 EtherCAT synchronisation achieves consistent seal jaw timing at 120 bags per minute.
- Robotic palletising and case packing servo drives in FMCG distribution centre automation projects across the Kingdom, where SIL 3 safety and 250 µs cycle time meet robot safety standard EN ISO 10218 requirements.
- Flexographic printing press servo drives for Saudi label and flexible packaging manufacturers, where 20-bit encoder resolution delivers ±0.1 mm print registration across six-colour print units.
- Saudi food and beverage production line cross-sealer and flying shear servo axes, where electronic gearing synchronises sealing jaw velocity to product infeed rate without mechanical cam gear systems.
- Pharmaceutical blister packaging machine servo drives at Saudi pharmaceutical manufacturers, where Lexium 62's position accuracy ensures consistent cavity alignment for international GMP compliance.
- NEOM advanced manufacturing zone robot integration projects, where Lexium 62 drives servo axes on custom-designed manufacturing robots being developed for the Kingdom's industrial technology showcase.
- Precision sheet-to-sheet laminating machine servo drives at Saudi offset printing and corrugated board manufacturers, where dual-axis configuration halves panel footprint in space-constrained press room installations.
مورد معتمد في المملكة العربية السعودية
احصل على عرض سعر لـ محرك سيرفو Schneider Lexium 62 المتقدم بـ EtherCAT
نرد خلال 4 ساعات. أرسل رقم الموديل LXM62DU60A21000 للحصول على سعر تنافسي مع التسليم في أنحاء المملكة العربية السعودية والخليج.
أسئلة شائعة حول محرك سيرفو Schneider Lexium 62 المتقدم بـ EtherCAT
أكثر الأسئلة شيوعاً من العملاء في المملكة العربية السعودية
