schneider-electric
عداد الطاقة شنايدر PowerLogic PM5000
رقم الموديل: PM5100
Accuracy Class: 0.5S (revenue grade)Measurement: V, I, f, kW, kVAr, kVA, PF, kWh, kVArhHarmonic Analysis: Up to 63rd harmonic (PM5560)Communication: Ethernet + RS485 Modbus built-in
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
عداد الطاقة شنايدر PowerLogic PM5000 — نظرة عامة
عداد الطاقة PowerLogic PM5000 من شنايدر يوفر قياس طاقة بدقة Class 0.5S وقياس جودة الطاقة الشامل بما في ذلك تحليل التوافقيات ورصد الطلب. يتوفر بمنفذ Ethernet مدمج للتكامل مع EcoStruxure PME. يُستخدم في منشآت أرامكو وسابك ومشاريع الطاقة الذكية في المملكة العربية السعودية، وتوفره راز الشرق الأوسط بدعم التكوين والمعايرة.
المواصفات الفنية
المواصفات الكاملة لـ PM5100
- Accuracy Class
- 0.5S (revenue grade)
- Measurement
- V, I, f, kW, kVAr, kVA, PF, kWh, kVArh
- Harmonic Analysis
- Up to 63rd harmonic (PM5560)
- Communication
- Ethernet + RS485 Modbus built-in
- Display
- Backlit LCD 128×64 pixels
- Mounting
- 96×96 mm panel cutout
- I/O Options
- Digital inputs, relay outputs, analog output
- EcoStruxure
- Direct PME integration
المميزات والفوائد
- Class 0.5S revenue-grade energy measurement accuracy meets IEC 62053-22 billing accuracy requirements for SEC billing reconciliation and internal energy cost allocation at facility level.
- Harmonic analysis up to 63rd harmonic in PM5560 provides IEC 61000-4-7 compliant power quality monitoring and harmonic source identification without a separate power quality analyser instrument.
- Direct Ethernet port enables connection to EcoStruxure PME without additional Modbus-Ethernet gateway hardware, simplifying power monitoring system installation and reducing network infrastructure cost.
- Time-of-use energy registers track energy consumption in multiple tariff periods, enabling detailed comparison with SEC time-of-use billing rates for commercial and industrial customers seeking demand management.
- Demand monitoring with configurable integration interval provides peak demand tracking and demand forecasting data to support SEC tariff optimisation and power factor correction investment decisions.
- Load profile recording at configurable intervals stores historical energy and demand data in the meter's internal memory, providing an independent data source for energy audit trail documentation.
- Flicker measurement (Pst, Plt) in PM5560 identifies voltage fluctuation sources from welding equipment, arc furnaces, and large motor starts that cause customer complaints on shared Saudi distribution networks.
التطبيقات الصناعية
- Sub-metering in ARAMCO industrial facilities for energy cost allocation between production departments and cost centres, where Class 0.5S accuracy satisfies ARAMCO's internal energy accounting audit requirements.
- Commercial building main incomer energy metering for SEC billing reconciliation and LEED energy performance certification at commercial towers across Riyadh, Jeddah, and Dammam.
- SABIC Jubail process area energy monitoring for plant energy efficiency programme tracking, where PM5000 meters at transformer feeder level identify high energy intensity areas for improvement initiatives.
- Power quality monitoring at NEOM smart city distribution substations to detect harmonic sources and voltage disturbances from the city's growing EV charging, LED lighting, and inverter-based equipment population.
- Industrial facility power factor measurement and automatic power factor correction system monitoring, where PM5000 provides the reactive power feedback required by PF correction panel automatic switching relays.
- SEC time-of-use tariff management for large commercial and industrial customers in Saudi Arabia, where PM5000 demand registers identify peak demand intervals that attract the highest tariff rates.
- Independent power producer (IPP) renewable energy export metering at REPDO solar and wind project grid connection points, where Class 0.5S accuracy satisfies Saudi grid code metering requirements for export settlement.
مورد معتمد في المملكة العربية السعودية
احصل على عرض سعر لـ عداد الطاقة شنايدر PowerLogic PM5000
نرد خلال 4 ساعات. أرسل رقم الموديل PM5100 للحصول على سعر تنافسي مع التسليم في أنحاء المملكة العربية السعودية والخليج.
أسئلة شائعة حول عداد الطاقة شنايدر PowerLogic PM5000
أكثر الأسئلة شيوعاً من العملاء في المملكة العربية السعودية
