وحدة تحكم المبنى KNX/IP من Schneider SpaceLynk
رقم الموديل: LSS100200
Protocols: KNX TP/IP, Modbus TCP/RTU, DALI-2, BACnet IP, HTTP RESTLogic Engine: LynkApps (graphical, no-code)Visualization: HTML5 web server (any browser)Event Log: 100,000 KNX telegrams
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
وحدة تحكم المبنى KNX/IP من Schneider SpaceLynk — نظرة عامة
وحدة SpaceLynk هي وحدة تحكم منطقي KNX/IP ومدخل بروتوكول متعدد، تُشكّل قلب أنظمة أتمتة المباني التجارية والفندقية والسكنية الراقية.
تُستخدم على نطاق واسع في المباني التجارية والفنادق الخمس نجوم ومشاريع NEOM والبحر الأحمر في المملكة العربية السعودية.
المواصفات الفنية
المواصفات الكاملة لـ LSS100200
- Protocols
- KNX TP/IP, Modbus TCP/RTU, DALI-2, BACnet IP, HTTP REST
- Logic Engine
- LynkApps (graphical, no-code)
- Visualization
- HTML5 web server (any browser)
- Event Log
- 100,000 KNX telegrams
- Cloud
- MQTT export, EcoStruxure integration
- Power Supply
- PoE IEEE 802.3af or 24 V DC
- Mounting
- DIN rail
- Standard
- KNX certified
المميزات والفوائد
- LynkApps graphical no-code logic engine enables building automation engineers without KNX programming certificates to create complex lighting, HVAC, and blind control sequences through drag-and-drop, reducing specialist labour dependency.
- Native Modbus TCP/RTU, DALI-2, BACnet IP, and HTTP REST integration in a single unit eliminates separate protocol gateways for multi-system Saudi commercial building automation projects.
- Built-in HTML5 web server provides browser-based building visualisation without installed software, accessible from facility manager smartphones and tablets for scene control and fault monitoring.
- 100,000-event local telegram log and MQTT cloud export enable long-term energy and operational data analysis, supporting Saudi Green Building Council energy performance documentation requirements.
- PoE IEEE 802.3af power supply eliminates 230 V wiring at the DIN rail panel, simplifying installation in IT-closet-mounted building automation cabinets common in Saudi Class-A office fit-outs.
- KNX IP tunnelling enables remote engineering and maintenance access via the building IP network, allowing Schneider engineers to update logic and troubleshoot from Riyadh without site visits to Jeddah or Dammam projects.
- Multi-user access with role-based permissions allows different facility management teams — building operations, energy management, and concierge — to access only the functions relevant to their role.
التطبيقات الصناعية
- Class-A commercial office tower building automation in Riyadh's King Abdullah Financial District, where SpaceLynk integrates KNX lighting, HVAC, and blind control with Modbus energy metering for SGBC certification.
- Five-star hotel room automation controller integration at Ritz-Carlton, Hilton, and IHG properties under development in Riyadh and Jeddah, where SpaceLynk scenes deliver branded guest room experience.
- NEOM commercial district office building automation hub, where SpaceLynk's EcoStruxure MQTT integration feeds building energy data to NEOM's city-wide energy management platform.
- Red Sea Project resort villa KNX control system, where SpaceLynk logic delivers automated welcome, evening, and departure scenes controlled via in-room tablets and voice assistants.
- Diriyah Gate cultural district building services automation for visitor experience and operational energy management, where SpaceLynk integrates KNX with BACnet HVAC systems from multiple contractors.
- Saudi university research centre and library building automation at KAUST and King Saud University, where SpaceLynk scheduling and occupancy-based control reduces HVAC energy consumption outside teaching hours.
- Mixed-use tower basement car park and retail podium lighting and ventilation control, where SpaceLynk's CO sensor and occupancy-triggered logic automates ventilation fan speed via Modbus VFD connection.
