قاطع حماية المحرك شنايدر TeSys GV2
رقم الموديل: GV2ME14
Trip Current Range: 0.1–32 A (adjustable)Voltage: Up to 690 V AC three-phaseShort-Circuit Withstand: 100 kA (with upstream fuses)Utilization: AC-3
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
قاطع حماية المحرك شنايدر TeSys GV2 — نظرة عامة
قاطع حماية المحرك TeSys GV2 من شنايدر إلكتريك يجمع وظائف مشغل الموتور اليدوي وريلاي الحمل الزائد الحراري والحماية من قصر الدائرة في جهاز واحد مدمج على سكة DIN من 0.1 إلى 32 أمبير. يُستخدم على نطاق واسع في المنشآت الصناعية ومحطات معالجة المياه ومراكز تحكم الآلات في المملكة العربية السعودية، وتوفره راز الشرق الأوسط من مخزون كامل.
المواصفات الفنية
المواصفات الكاملة لـ GV2ME14
- Trip Current Range
- 0.1–32 A (adjustable)
- Voltage
- Up to 690 V AC three-phase
- Short-Circuit Withstand
- 100 kA (with upstream fuses)
- Utilization
- AC-3
- Aux Contact
- 1 NO + 1 NC (trip cause signalling)
- Mounting
- DIN rail (45 mm)
- Handle
- On/Off/Trip-free
- Standard
- IEC 60947-2 / IEC 60947-4-1
المميزات والفوائد
- Combined MPCB replaces separate fuse + contactor + overload relay assembly in small motor protection circuits, reducing panel component count by three devices per motor circuit and saving significant DIN rail space.
- Adjustable magnetic trip threshold covers motor starting currents from 6 to 12 times Ie, enabling precise coordination with the protected motor's starting current without time delay setting complications.
- Trip cause differentiation between thermal overload and short-circuit in the auxiliary contact output signals the machine PLC with the fault type, enabling appropriate diagnostic response and restart decision logic.
- 100 kA short-circuit withstand rating (with upstream fuses) provides very high fault current protection performance in a compact device, exceeding the fault level available at most Saudi industrial distribution boards.
- Manual operating handle doubles as IEC 60204-1 compliant manual motor operator isolation switch, eliminating the need for a separate isolation switch in machine safety circuits.
- Trip-free mechanism prevents re-closing against a persisting fault regardless of handle position, providing protection against operator-forced reset in fault conditions that could damage equipment or cause injury.
- Compact 45 mm DIN rail mounting allows high-density multi-motor protection in MCC door-mounted feeder sections and machine control cabinet door panels with minimum panel depth requirements.
التطبيقات الصناعية
- Small pump and fan motor protection in NWC water treatment plant instrument panels and chemical dosing skids, where the single-device solution reduces panel assembly time and component procurement complexity.
- Conveyor, mixer, and auxiliary drive motor protection in MODON industrial estate OEM machinery, where GV2 replaces three separate components in a single 45 mm DIN rail slot per motor circuit.
- HVAC fan coil unit and small pump motor protection in commercial building services panels across Riyadh, Jeddah, and Dammam, where panel space constraints in ceiling-mounted FCU panels favour the compact GV2 format.
- Instrument air compressor and pneumatic system motor protection in petrochemical panel buildings at SABIC and ARAMCO facilities, where the trip cause output integrates with the plant DCS fault management system.
- Machine tool coolant pump and lubrication pump motor protection in Saudi industrial machinery, where the GV2's IEC 60204-1 isolation handle satisfies CE Machinery Directive requirements without an additional isolator.
- Small agitator and mixer motor protection in food processing equipment at MODON Jeddah and Riyadh food industrial zones, where the compact size suits the stainless steel panel enclosures required by hygiene standards.
- Desalination plant dosing pump and small auxiliary motor protection at SWCC coastal desalination facilities, where corrosion-resistant construction and robust trip mechanism handle the humid saline environment.
