حماية مشغل المحرك شنايدر TeSys GV3
رقم الموديل: GV3P40
Trip Current Range: 18–150 A (adjustable)Voltage: Up to 690 V AC three-phaseShort-Circuit Withstand: Up to 100 kA (with fuses)Front Panel Protection: IP54 (door-mounted)
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
حماية مشغل المحرك شنايدر TeSys GV3 — نظرة عامة
حماية مشغل المحرك TeSys GV3 من شنايدر إلكتريك يغطي 18 إلى 150 أمبير للمحركات المتوسطة الحجم حتى 690 فولت. يجمع الحماية الحرارية المغناطيسية والعزل في جهاز واحد مع IP54 أمامي وتوافق مع كونتاكتورات TeSys D. يُستخدم في مراكز تحكم محركات أرامكو ومحطات ضخ المياه في المملكة العربية السعودية، وتوفره راز الشرق الأوسط من مخزون محلي.
المواصفات الفنية
المواصفات الكاملة لـ GV3P40
- Trip Current Range
- 18–150 A (adjustable)
- Voltage
- Up to 690 V AC three-phase
- Short-Circuit Withstand
- Up to 100 kA (with fuses)
- Front Panel Protection
- IP54 (door-mounted)
- Aux Contact
- Add-on blocks available
- Direct Mounting
- Plug-in kit for LC1D contactors
- Handle
- On/Off/Trip-free rotary
- Standard
- IEC 60947-2
المميزات والفوائد
- Medium motor range (18–150 A) bridges the gap between GV2 (up to 32 A) and MCCB solutions, providing a compact MSP solution for the 15–75 kW motor range most common in Saudi industrial MCCs.
- IP54 front panel protection when door-mounted shields the rotary operator handle from dust and water splash without a separate seal kit, suitable for panels in dusty Saudi industrial environments.
- Direct plug-in mounting kit for TeSys LC1D contactors creates a complete compact motor starter assembly on a shared mounting bracket, reducing panel space per motor starter by up to 40% versus a separate DIN rail assembly.
- Thermal trip adjustment to match motor full-load current rating optimises thermal protection without time delay, preventing nuisance tripping from motor starting current while protecting against genuine overload conditions.
- Rotary handle serves as IEC 60204-1 manual motor operator for isolation without an additional disconnector, satisfying both Saudi Electricity Company installation requirements and international machinery safety standards.
- 100 kA short-circuit withstand with upstream fuses provides protection at the fault current levels available from Saudi Arabia's heavy industrial distribution systems without requiring a higher-rated MCCB solution.
- Add-on auxiliary contact blocks with trip cause differentiation integrate with plant DCS and PLC fault management systems, providing remote fault status indication for MCCs in unmanned substations.
التطبيقات الصناعية
- 15–75 kW motor protection in ARAMCO Eastern Province facility MCCs, where GV3P-based compact starters reduce MCC panel footprint compared to conventional MCCB-plus-contactor-plus-overload assemblies.
- Submersible pump motor protection (22–55 kW) in NWC water booster stations serving Riyadh's northern residential expansion zones, where compact panel design reduces kiosk size and civil infrastructure cost.
- Process pump and fan motor starters in SABIC Jubail plant MCCs, where the direct-mount contactor kit creates a compact integrated starter meeting SABIC panel space efficiency requirements.
- HVAC large pump and AHU fan motor starters in commercial building services panels across Jeddah and Dammam, where IP54 front panel protection handles the humidity in basement mechanical plant rooms.
- Industrial compressor motor protection at cement and aggregate processing facilities, where the adjustable magnetic trip handles the compressor's high starting current without requiring extended time-delay coordination.
- Cooling tower fan motor starters at data centre and industrial facility cooling systems, where the compact GV3P format fits the limited panel space in rooftop cooling plant enclosures.
- Mine and mineral processing medium motor protection at Ma'aden facilities, where robust thermal-magnetic protection handles the variable load and ambient temperature swings of outdoor crushing and conveying duty.
مورد معتمد في المملكة العربية السعودية
احصل على عرض سعر لـ حماية مشغل المحرك شنايدر TeSys GV3
نرد خلال 4 ساعات. أرسل رقم الموديل GV3P40 للحصول على سعر تنافسي مع التسليم في أنحاء المملكة العربية السعودية والخليج.
