ريلاي الحماية الرقمي Schneider ViP300
رقم الموديل: 59649
Protection Functions: ANSI 50/51, 50N/51N, 46Time Characteristics: IDMT IEC (EI, VI, SI, LTI) and definite timeInstantaneous: 1–30 × In (adjustable)Auxiliary Supply: Self-powered from CT secondaries
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
ريلاي الحماية الرقمي Schneider ViP300 — نظرة عامة
ريلاي ViP300 هو ريلاي حماية رقمي للمغذيات والمحولات في محطات التوزيع الثانوية، يعمل بالطاقة الذاتية من مدخلات CT دون الحاجة إلى إمداد مساعد منفصل.
يُستخدم في تحديث الريلايات الكهروميكانيكية في محطات التوزيع الثانوية لدى SEC وأرامكو في المملكة.
المواصفات الفنية
المواصفات الكاملة لـ 59649
- Protection Functions
- ANSI 50/51, 50N/51N, 46
- Time Characteristics
- IDMT IEC (EI, VI, SI, LTI) and definite time
- Instantaneous
- 1–30 × In (adjustable)
- Auxiliary Supply
- Self-powered from CT secondaries
- Target Indicators
- Mechanical, per function
- Test Facility
- Built-in secondary injection sockets
- Communication
- Optional RS-232 port
- Standard
- IEC 60255
المميزات والفوائد
- Self-powered operation from CT secondary current eliminates separate auxiliary supply wiring, enabling cost-effective relay retrofit in legacy secondary substations with limited auxiliary voltage infrastructure.
- Mechanical target indicators identify which protection function operated after a trip without laptop or communications access, enabling rapid fault type diagnosis at remote Saudi secondary substations.
- Built-in secondary injection test sockets allow protection function verification without disconnecting CT wiring, reducing test time and eliminating the risk of open-circuiting CT secondaries during field testing.
- IEC standard inverse time curves (EI, VI, SI, LTI) selectable by front-panel switch satisfy all common overcurrent coordination requirements in Saudi Arabia's secondary distribution network without software parameterisation.
- Compact panel-mount format with standard 4U relay case fits existing relay panel cut-outs in IDT/CDT relay replacement projects without mechanical modification to the relay panel.
- Negative phase sequence (NPS) protection detects unbalanced loading and phase reversal conditions, protecting distribution transformers and induction motors from overheating caused by supply unbalance.
- Earth fault high-set (50N) instantaneous element provides fast clearance of ground faults on secondary distribution feeders, minimising fault damage at SEC secondary substations serving residential customers.
التطبيقات الصناعية
- SEC secondary substation electromechanical relay replacement programme, where ViP300 replaces aging CDT and IDT relays with self-powered digital protection without auxiliary supply infrastructure investment.
- ARAMCO Dhahran facility secondary distribution protection upgrade, where ViP300 self-powered feature eliminates auxiliary wiring work in crowded legacy switchgear cubicles during live substation upgrade campaigns.
- NWC water distribution pump station switchgear protection upgrade, where ViP300 provides motor and feeder overcurrent protection with built-in NPS for unbalanced 3-phase supply detection.
- MODON industrial estate tenant feeder protection at secondary distribution boards, where ViP300 provides cost-effective overcurrent and earth fault protection with minimal commissioning complexity.
- Saudi hospital and healthcare facility secondary distribution protection at site distribution substations, where ViP300 NPS detection protects sensitive medical equipment from supply phase imbalance.
- Commercial building basement substation feeder protection upgrade at Riyadh and Jeddah towers, where ViP300 replaces obsolete electromechanical relays with digital protection and mechanical fault indication.
- Telecom infrastructure site secondary distribution protection at STC and Zain base station substations, where self-powered ViP300 protects critical telecom supply without separate battery-backed auxiliary supply.
