منتج شنايدر METSEPM2130

المواصفات الفنية

المواصفات الكاملة لـ PM2130

Range

EasyLogic

Product name

EasyLogic PM2100

Product or component type

Power meter

Device short name

PM2130

Device application

Sub billing; Power monitoring

Power quality analysis

total harmonic distortion; up to the 31st harmonic

Accuracy class

Class 1 reactive energy conforming to IEC 62053-24; Class 0.5S active energy conforming to IEC 62053-22; Class 5 harmonic distortion (I THD & U THD)

Measurement accuracy

Apparent power +/- 0.5 %; Active energy +/- 0.5 %; Reactive energy +/- 1 %; Active power +/- 0.5 %; Voltage +/- 0.5 %; Power factor +/- 0.01; Current +/- 0.5 %; Frequency +/- 0.05 %

Measurement current

5…6000 mA

Measurement voltage

35…480 V AC 50/60 Hz between phases; 20…277 V AC 50/60 Hz between phase and neutral; 480…999000 V AC 50/60 Hz with external VT

Frequency measurement range

45…65 Hz

Us rated supply voltage

80...277 V AC 45...65 Hz +/- 10 %; 100...277 V DC +/- 10 %

Network frequency

50 Hz; 60 Hz

Ride-through time

50 ms 120 V AC typical; 50 ms 230 V AC typical; 50 ms 125 V DC typical

In rated current

1 A; 5 A

Maximum power consumption in VA

8 VA at 277 V AC
