Siemens
قاطع الفيوز NH سيمنز 3NX8
رقم الموديل: 3NX8012
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
قاطع الفيوز NH سيمنز 3NX8 — نظرة عامة
قاطع الفيوز NH سيمنز 3NX8 يجمع مفتاح العزل الدوار مع حوامل فيوز NH في وحدة واحدة للتيارات من 100 إلى 1250 أمبير بقدرة قطع حتى 120 كيلوأمبير. يتيح استخراج الفيوز عمودياً في الحالة المشغلة.
يُستخدم كجهاز حماية معياري للمغذيات الصناعية في لوحات التوزيع الرئيسية في المملكة. توفر راز الشرق الأوسط هذه الأجهزة مع جميع أحجام وصلات الفيوز NH والملحقات.
المواصفات الفنية
المواصفات الكاملة لـ 3NX8012
- Current Range
- 100–1250 A
- Voltage
- 690 V AC
- NH Sizes
- 00, 0, 1, 2, 3
- Breaking Capacity
- Up to 120 kA (with NH fuse)
- Handle
- Rotary, padlockable in OFF
- Fuse Extraction
- Vertical, tool-operated
- Aux Contact
- Optional 1 NO + 1 NC
- Mounting
- DIN rail or base-plate
- Compliance
- IEC 60947-3, IEC 60269-2
المميزات والفوائد
- Combined NH fuse holder and isolating switch in a single type-tested device reduces panel footprint compared to separate fuse holders plus a disconnecting switch in industrial distribution boards.
- Vertical NH fuse extraction under live conditions using a certified insulated fuse puller eliminates the need to de-energise the distribution board for routine fuse replacement at continuously operating process plants.
- NH fuse link independence from switch body allows protection characteristics (gG, gM, aM) and current rating to be changed by replacing only the fuse link, optimising coordination without replacing switch hardware.
- Breaking capacity up to 120 kA with NH gG fuses provides the highest LV fault current interruption capability, meeting prospective fault levels at large transformer LV terminals and generator-backed substations.
- Padlockable rotary handle in OFF satisfies LOTO isolation requirements for individual feeder circuits at Saudi industrial distribution boards.
- NH size range 00–3 in a common product family covers all industrial feeder current ratings from 100 A motor feeders to 1250 A main distribution incomers from a single procurement source.
- Optional auxiliary contact provides remote confirmation of isolation status for unmanned distribution boards at remote Saudi pumping and utility facilities.
التطبيقات الصناعية
- Industrial feeder protection in main distribution boards at SABIC petrochemical sub-distribution panels, where 3NX8 high breaking capacity protects circuits from transformer-backed fault currents exceeding 50 kA.
- Transformer LV terminal protection at industrial substations serving MARAFIQ utility customers, where NH aM motor fuse links provide back-up protection for the LV circuit breaker.
- MCC incoming feeder protection at large motor control centres at Aramco and SABIC process plants, combining incomer isolation and short-circuit protection.
- Distribution board incomer protection at commercial and government buildings, where 400–800 A NH size 1 and 2 fuse switches protect the main circuit from upstream fault currents.
- Generator output cable protection at hospitals, data centres, and critical infrastructure diesel generators, where NH gG fuse links protect output cables before the generator excitation responds.
- Welding transformer and arc furnace feeder protection at steel fabrication facilities, where NH aM motor-duty fuse links handle high inrush currents without nuisance operation.
- Water utility sub-distribution feeder protection at NWC remote facilities, where combined fuse-switch function reduces maintenance exposure to live circuits during routine fuse inspection.
مورد معتمد في المملكة العربية السعودية
احصل على عرض سعر لـ قاطع الفيوز NH سيمنز 3NX8
نرد خلال 4 ساعات. أرسل رقم الموديل 3NX8012 للحصول على سعر تنافسي مع التسليم في أنحاء المملكة العربية السعودية والخليج.
