Schneider Electric Acti9 iC60N Miniature Circuit Breaker
Model: A9F74210
4-hour response · Pricing in SAR · Delivery across all KSA regions
A9F74210 — Schneider Electric Acti9 iC60N Miniature Circuit Breaker
The Schneider Electric Acti9 iC60N is a professional-grade miniature circuit breaker (MCB) covering 1 A to 63 A in 1P, 2P, 3P, and 4P configurations for final distribution circuit protection in residential, commercial, and light industrial installations to 230/400 V AC. The iC60N provides a rated breaking capacity of 6 kA at 230 V (10 kA with iC60H), with Type B, C, and D trip characteristics covering the full range of resistive, inductive, and high-inrush load protection requirements. The Acti9 product line is designed as a complete ecosystem — the iC60N is mechanically compatible with the full range of Acti9 auxiliary devices including shunt trips, undervoltage releases, auxiliary contacts, and iOF indicator contacts — enabling sophisticated panel designs from a single coordinated product family.
The iC60N incorporates Schneider Electric's innovative Visi-Trip indicator, a separate viewing window that clearly shows the tripped state in orange — distinguishing a fault trip from a manually switched-off position — even when the MCB is installed in a fully loaded distribution board where the main switch position is partially obscured. The wire range accommodates solid and stranded conductors from 1 mm² to 25 mm² depending on current rating, with double terminal option available for looping conductor connections in residential distribution board wiring. The iC60N's IEC 60898-2 certification for industrial applications (in addition to IEC 60898-1 for residential) gives it broader deployment approval than standard domestic MCBs.
The Acti9 iC60N Saudi Arabia installed base spans the full range of final distribution applications from residential villa electrical panels complying with SASO electrical requirements to commercial building tenant distribution boards to small industrial plant final circuit protection. Saudi Electricity Company (SEC) approved panel builders use iC60N as the standard final circuit MCB for commercial distribution boards throughout the Kingdom. ROSHN housing developments, Vision 2030 new city infrastructure, and the massive hotel and hospitality expansion in Makkah, Madinah, and the Red Sea coast all consume large volumes of Acti9 iC60N MCBs.
Razz Middle East stocks Acti9 iC60N in all current ratings from 6 A to 63 A, all pole configurations (1P to 4P), and all trip characteristics (B, C, D) for same-day supply to electrical contractors and panel builders across Saudi Arabia.
Technical Specifications
Full specifications for the A9F74210
- Current Range
- 1–63 A
- Voltage
- 230/400 V AC
- Breaking Capacity
- 6 kA (iC60N) / 10 kA (iC60H)
- Trip Characteristics
- B / C / D
- Poles
- 1P / 2P / 3P / 4P
- Trip Indicator
- Visi-Trip (orange)
- Standard
- IEC 60898-1 / IEC 60898-2
- Acuity Range
- Compatible with full Acti9 accessory range
- Wire Range
- 1–25 mm²
Key Features & Benefits
- Visi-Trip indicator in a separate orange window clearly distinguishes a fault trip from a manually off position, enabling rapid circuit identification in fully loaded distribution boards during fault diagnosis.
- Full Acti9 accessory ecosystem compatibility including shunt trip, undervoltage release, iOF indicator contact, and remote operation module enables sophisticated protection, monitoring, and remote control from a single MCB family.
- IEC 60898-2 industrial certification in addition to IEC 60898-1 residential certification broadens deployment approval to commercial and light industrial applications under a single product specification.
- Type B, C, and D trip characteristics cover resistive, inductive motor, and high-inrush load protection from a single mechanical product with trip characteristic selectable at order, simplifying panel BOM management.
- Double terminal option for looping conductor connections reduces the number of discrete terminals required in residential distribution boards, saving board assembly time and terminal strip cost.
- 6 kA standard breaking capacity (10 kA with iC60H variant) covers the fault current levels available from Saudi Arabia's residential and commercial supply networks without requiring upgraded cable or distribution equipment.
- Compact 18 mm per pole DIN rail width allows high-density circuit protection in residential consumer units and commercial distribution boards where multiple circuits share limited enclosure space.
Industrial Applications in Saudi Arabia
- Residential villa and apartment final circuit protection in ROSHN and private residential developments across Saudi Arabia, providing SEC-compliant circuit protection for lighting, socket, and appliance circuits.
- Commercial tenant distribution board circuit protection in office towers across Riyadh's KAFD and Jeddah's commercial district, where iC60N serves as the standard final circuit MCB in SEC-approved panel designs.
- Hotel room and public area circuit protection in Makkah's Haram-adjacent hotel towers and Madinah's hospitality district, where high occupancy intensity demands reliable, easily replaced circuit protection devices.
- Industrial control panel final circuit protection for 230 V auxiliary supply circuits including PLC power supplies, instrumentation, and control transformers at MODON industrial estate facilities.
- Healthcare facility distribution board circuit protection in Ministry of Health hospitals and private medical facilities, where IEC 60898-2 industrial certification covers the commercial building classification of healthcare premises.
- Educational institution and government building electrical distribution under Ministry of Education and Ministry of Finance infrastructure programmes, where Acti9 products are standard specified components.
- NEOM and Red Sea Project resort hotel and residential electrical installation circuit protection, where modern luxury facilities require the latest generation distribution products with smart monitoring capability via Acti9 accessories.
Industrial Supplier in Saudi Arabia
Get a Quote for the Schneider Electric Acti9 iC60N Miniature Circuit Breaker
We respond within 4 business hours. Send model A9F74210 for competitive pricing in SAR with delivery across Saudi Arabia and the GCC.
