عداد جودة الطاقة المتقدم شنايدر PowerLogic PM8000
رقم الموديل: PM8243
Accuracy Class: 0.2S (highest utility grade)Harmonics: Up to 63rd + inter-harmonics + sub-harmonicsFlicker: Pst, Plt, Pinst measurementWaveform Capture: 256 samples/cycle continuous
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
عداد جودة الطاقة المتقدم شنايدر PowerLogic PM8000 — نظرة عامة
عداد PowerLogic PM8000 من شنايدر هو جهاز قياس جودة الطاقة المتقدم بدقة Class 0.2S مع مراقبة شاملة لجودة الطاقة وفق IEC 61000-4 وتسجيل شكل الموجة ومعيار IEC 61850. يُستخدم في مراقبة جودة الطاقة للشبكة الكهربائية السعودية ومنشآت أرامكو وبنية NEOM الذكية، وتوفره راز الشرق الأوسط مع دعم التكوين والتكامل.
المواصفات الفنية
المواصفات الكاملة لـ PM8243
- Accuracy Class
- 0.2S (highest utility grade)
- Harmonics
- Up to 63rd + inter-harmonics + sub-harmonics
- Flicker
- Pst, Plt, Pinst measurement
- Waveform Capture
- 256 samples/cycle continuous
- Communication
- Ethernet + IEC 61850 + Modbus
- PQ Events
- RVC, transients, voltage sags/swells
- Optional
- Cellular modem for remote monitoring
- Standard
- IEC 61000-4-30 Class A
المميزات والفوائد
- Class 0.2S energy measurement accuracy — the highest utility billing grade — satisfies Saudi grid code metering requirements for IPP export settlement and large industrial customer billing reconciliation.
- IEC 61000-4-30 Class A power quality compliance covers the full measurement requirement set for connection point power quality assessment under SEC's network code, eliminating additional instrumentation.
- Waveform capture at 256 samples per cycle with event-triggered storage enables post-event root cause analysis of process trips and equipment malfunctions caused by power supply disturbances.
- Inter-harmonic measurement identifies non-integer frequency components from cycloconverters, arc furnaces, and wind turbine generators that standard harmonic meters do not detect, providing complete PQ characterisation.
- IEC 61850 communication enables direct integration into substation automation systems at SEC distribution substations and industrial plant protection panels without a Modbus-IEC 61850 protocol converter.
- Optional cellular modem card provides remote access to power quality data at unstaffed locations including remote pump stations, wind farms, and solar grid connection points across Saudi Arabia's dispersed infrastructure.
- EcoStruxure Power Monitoring Expert integration with automatic PQ trend report generation provides facility managers and SEC network operators with scheduled PQ compliance reports without manual data export.
التطبيقات الصناعية
- SEC distribution substation power quality monitoring for harmonic and flicker assessment at large industrial customer connection points, where Grid Code compliance requires IEC 61000-4-30 Class A measurement.
- ARAMCO facility critical instrument power supply quality monitoring, where PM8000 waveform capture identifies power quality events causing instrumentation malfunctions in process control systems.
- NEOM smart grid distribution substation PQ instrumentation, where PM8000 provides the power quality baseline data required for the city's electricity network performance monitoring and reporting.
- Large arc furnace and electrolyser facility grid impact monitoring at steel and aluminium production facilities in Jubail and Ras Al Khair, where IEC 61000-3-12 harmonic injection assessment is required.
- REPDO solar and wind farm grid connection point PQ monitoring for grid code compliance and export metering, where cellular modem remote access eliminates staffing costs at remote desert and coastal sites.
- Pharmaceutical and semiconductor facility critical power supply quality monitoring, where PM8000 waveform records provide evidence for equipment warranty claims and FDA process validation deviation reports.
- Data centre utility supply quality monitoring in Riyadh and Jeddah hyperscale facilities, where voltage sag and swell event capture supports UPS performance validation and generator transfer time studies.
