Eaton Power Xpert C Power Meter

The Eaton Power Xpert C Power Meter is a high-accuracy Class 0.2S revenue-grade power metering device designed for billing, sub-billing, cost allocation, and energy management applications in commercial, industrial, and utility installations across Saudi Arabia. The PXC-1X001 fits a standard 96×96 mm DIN panel cutout and measures all critical electrical parameters including true RMS voltage and current, active and reactive power, power factor, frequency, THD, and demand with Class 0.2S accuracy — the highest accuracy class specified by IEC 62053-22 and recognised by the Saudi Electricity Company for utility interface metering. Its dual-port communication architecture supports simultaneous Modbus RTU and PROFIBUS DP operation, enabling integration into both energy management software and process automation systems without network switching.

The Power Xpert C's internal memory stores 8,760 hours of trend data at 15-minute intervals — one full year of energy profiles — directly accessible via the front-panel USB port or Modbus register reads, eliminating the need for a dedicated data logger in most sub-metering applications. The built-in IEC 61000-4 series immunity certification ensures stable operation in the high-interference environment of switchgear panels alongside contactors, drives, and MCBs. Its backlit graphical LCD displays multi-parameter energy data simultaneously, allowing local operators to read voltage, current, power, and power factor from a single screen without navigating menus — a practical advantage in Saudi Arabia's busy industrial substations.

In Saudi Arabia, the Power Xpert C is widely deployed for SEC cost-of-supply metering at point-of-delivery in large industrial consumers, sub-metering within NEOM smart-city zones where per-district energy billing is required by the master development plan, and HVAC energy monitoring in Ministry of Education university campus projects specifying LEED energy sub-metering. SABIC and Saudi Aramco facility engineers use the meter for production cost analysis across process areas, allocating utility costs to individual cost centres for ISO 50001 energy management compliance.

Razz Middle East supplies the Power Xpert C with full Modbus register maps, integration guides, and configuration support for common SCADA, BMS, and energy management platforms. We provide local stock, SAR pricing, and on-site commissioning support across Riyadh, Dammam, Jubail, and Jeddah. SEC technical approval documentation is available on request for utility-grade metering applications.
