Siemens SENTRON PAC3200 Power Meter
Model: 7KM2112-0BA00-3AA0
4-hour response · Pricing in SAR · Delivery across all KSA regions
7KM2112-0BA00-3AA0 — Siemens SENTRON PAC3200 Power Meter
The Siemens SENTRON PAC3200 is the benchmark multifunction power meter for industrial energy management in Saudi Arabia, measuring the complete set of electrical parameters — voltage (L-L and L-N), current, active power (kW), reactive power (kVAr), apparent power (kVA), power factor, frequency, energy (kWh and kVArh), and harmonics to the 40th order — from a single 96×96 mm panel-mount device. Class 1 accuracy for active energy satisfies SEC metering accuracy requirements for large commercial and industrial consumers, while harmonic analysis to the 40th order identifies power quality issues from variable speed drives, UPS systems, and switching power supplies that cause transformer overheating and premature capacitor failure.
The PAC3200 communicates via RS-485 Modbus RTU as standard, placing it on any BMS or industrial SCADA network with a simple two-wire connection. The large graphical 128×64 LCD provides immediate local readout of all energy parameters without a PC at remote panel locations. Min/max memory with timestamp records peak demand, minimum voltage, and maximum current for capacity planning and power quality investigation.
In Saudi Arabia, the SENTRON PAC3200 is the standard sub-metering device in industrial facilities and commercial buildings under SEC large-consumer energy management requirements, ARAMCO facility energy programmes, and MODON industrial estate per-tenant consumption tracking. Vision 2030 sustainability programmes specify sub-metering for green building and industrial energy certification, and the PAC3200's Modbus connectivity and Class 1 accuracy satisfy both technical measurement and data logging requirements.
Razz Middle East supplies SENTRON PAC3200 meters from local stock with Modbus register mapping, SCADA integration, and energy management configuration support.
Technical Specifications
Full specifications for the 7KM2112-0BA00-3AA0
- Accuracy
- Class 1 (kWh), Class 2 (kVArh) per IEC 62053
- Measurements
- V, I, P, Q, S, PF, f, kWh, kVArh, harmonics to 40th order
- Voltage Input
- 100–400 V AC direct
- Current Input
- Via 5A CT secondary
- Communication
- RS-485 Modbus RTU
- Display
- Graphical 128×64 LCD
- Panel Cutout
- 96×96 mm
- Supply
- 100–240 V AC or 24 V DC
Key Features & Benefits
- Class 1 active energy accuracy per IEC 62053-21 satisfies SEC energy metering requirements for large consumers, enabling the PAC3200 to serve as the primary billing sub-meter in tenant energy allocation systems.
- Harmonic analysis to the 40th order quantifies voltage and current distortion from VFDs and UPS systems, enabling diagnosis of transformer overheating and capacitor bank failure root causes.
- Modbus RTU RS-485 communication integrates the PAC3200 into any SCADA, BMS, or energy management system using a standard two-wire connection without additional gateways.
- Min/max memory with timestamp for all measured parameters provides a continuous record of peak demand and minimum voltage for capacity planning and power quality investigation without a separate data logger.
- Large graphical LCD with plain-text display provides immediate local readout of all energy parameters during commissioning and routine maintenance without a SCADA terminal.
- Wide 100–400 V direct voltage input covers all standard LV distribution voltages from 110 V single-phase through 400 V three-phase without step-down transformers.
- Expandable with SENTRON communication modules for PROFINET or PROFIBUS output, feeding PAC3200 data directly into TIA Portal SCADA or SIMATIC energy management software.
Industrial Applications in Saudi Arabia
- Sub-metering at ARAMCO facility distribution boards for energy consumption tracking, peak demand management, and SEC large-consumer billing verification.
- MODON industrial estate tenant energy sub-metering for per-unit consumption billing, where PAC3200 Modbus data feeds the centralised energy management platform.
- Commercial tower floor-by-floor and tenant energy metering in Riyadh and Jeddah's major real estate developments, where Class 1 accuracy satisfies tenant electricity cost allocation requirements.
- SABIC plant distribution circuit energy monitoring for production energy intensity KPI tracking aligned with SABIC's sustainability reporting commitments.
- Hospital and healthcare facility energy management for SEC large-consumer reporting, providing per-wing consumption visibility for facility management.
- NEOM and Vision 2030 project energy management systems, where PAC3200 meters provide the granular real-time energy data required for smart energy platforms.
- Industrial transformer loading monitoring to detect harmonic-current overloading — common in high-VFD-penetration facilities — enabling capacity management before premature transformer failure.
