Siemens SENTRON PAC4200 Power Quality Analyzer
Model: 7KM4212-0BA00-3AA0
4-hour response · Pricing in SAR · Delivery across all KSA regions
7KM4212-0BA00-3AA0 — Siemens SENTRON PAC4200 Power Quality Analyzer
The Siemens SENTRON PAC4200 is a Class S power quality analyzer designed for comprehensive electrical network monitoring in industrial, commercial, and utility installations where IEC 62586 Class S power quality data is required for regulatory compliance, energy auditing, and equipment protection studies. The PAC4200 measures all relevant electrical parameters: three-phase voltage (V), current (A), active power (P), reactive power (Q), apparent power (S), power factor, THD, individual harmonics to the 63rd order, flicker (Pst and Plt), and voltage/current unbalance — providing the complete power quality dataset required for IEC 61000-4 series compliance assessments.
The PAC4200's hardware platform combines a high-resolution 3.5-inch colour TFT display for local readout with dual communication ports: RS-485 Modbus RTU for integration into existing plant SCADA systems, and Ethernet for direct web-server access and Modbus TCP integration into SIMATIC Energy Suite or third-party energy management platforms. The internal data logger captures min/max trend data and power quality events with timestamps, providing an independent on-device record that can be retrieved via USB or network without a continuously connected server. With a 96×96 mm DIN 43700 panel cutout, the PAC4200 installs into existing panel front doors without panel replacement.
In Saudi Arabia, the SENTRON PAC4200 KSA is specified at power quality monitoring points in industrial facilities undergoing SEC power quality compliance assessments, particularly in plants with significant non-linear loads such as variable speed drives, arc furnaces, and large UPS systems. Saudi Arabia's SEEC programme and the National Energy Efficiency Program (NEEP) require documented power quality data for facilities above certain consumption thresholds, and the PAC4200's Class S certification provides the legally defensible measurement data required for these submissions. At SABIC steel plants and Hadeed Jubail, arc furnace flicker measurement via the PAC4200 supports compliance with SEC's flicker injection limits.
Razz Middle East supplies PAC4200 analyzers with full configuration, including Modbus register mapping for integration to DCS and SCADA systems, SENTRON powerconfig setup, and power quality report generation for regulatory submissions.
Technical Specifications
Full specifications for the 7KM4212-0BA00-3AA0
- Power Quality Class
- IEC 62586 Class S
- Harmonics
- 2nd–63rd order (THD + individual)
- Flicker
- Pst, Plt (IEC 61000-4-15)
- Measurements
- V, I, P, Q, S, PF, unbalance, freq
- Communication
- RS-485 Modbus RTU + Ethernet Modbus TCP
- Display
- 3.5" colour TFT
- Data Logger
- Internal min/max + event storage
- CT Input
- 1 A / 5 A secondary
- Panel Cutout
- 96×96 mm (DIN 43700)
- Compliance
- IEC 62586 Class S, CE
Key Features & Benefits
- IEC 62586 Class S power quality certification provides legally defensible measurement data for Saudi SEEC programme submissions and SEC power quality compliance reporting at industrial tariff accounts.
- Individual harmonic measurement to the 63rd order with waveform capture identifies dominant harmonic sources in VFD-dense installations, supporting filter design to meet SEC harmonic injection limits at the point of common coupling.
- IEC 61000-4-15 flicker measurement (Pst and Plt) provides the data required for compliance with SEC's voltage flicker injection limits, particularly relevant for arc furnace operators and large welding machine facilities.
- Dual RS-485 Modbus RTU and Ethernet Modbus TCP ports allow simultaneous integration with the plant SCADA via RS-485 and direct web browser access via the integrated web server from engineering workstations.
- Internal data logger with min/max trending and event timestamping operates independently of network connectivity, ensuring power quality records are maintained during communication outages and server downtime.
- 96×96 mm DIN 43700 panel cutout retrofits directly into existing panel doors without panel replacement, reducing upgrade cost for Saudi facilities managers adding power quality monitoring to existing distribution boards.
- SENTRON powerconfig integration provides centralised energy management dashboard covering multiple PAC4200 instruments across a facility, generating automated power quality reports for SEEC energy audit submissions.
Industrial Applications in Saudi Arabia
- Power quality compliance monitoring at SEC industrial tariff accounts in Saudi Arabia under the SEEC energy efficiency programme, where IEC 62586 Class S data is required for annual energy audit documentation.
- Arc furnace and ladle furnace flicker measurement at Hadeed and SABIC steel production facilities in Jubail, where Pst and Plt data from the PAC4200 supports SEC flicker injection limit compliance assessment.
- Variable speed drive harmonic audit measurements at petrochemical plants with large VFD populations, where THD and individual harmonic data up to the 63rd order identifies the need for harmonic filter installation.
- Utility interconnection power quality monitoring at Saudi solar PV and wind energy projects under Vision 2030, where IEC 62586 Class S data demonstrates grid code compliance to the Saudi grid operator.
- Data centre electrical infrastructure monitoring where PAC4200 instruments at UPS outputs and main distribution panels track total harmonic distortion to verify ASHRAE and TIA-942 data centre electrical quality standards.
- Hospital electrical system power quality assessment at Ministry of Health facilities, where harmonics from MRI and radiology equipment are measured to verify compliance with medical electrical safety standards.
- Large commercial building power quality audit at King Abdullah Financial District (KAFD) and Jeddah Central development towers, where the PAC4200 provides baseline measurement data for LEED energy and atmosphere credits.
