WEG CFW11MD Multi-Drive Cabinet with Common DC Bus

The WEG CFW11MD Multi-Drive Cabinet is an advanced power electronics solution that integrates up to four CFW11 inverter modules on a shared Active Front End (AFE) rectifier and common DC bus architecture, delivering significant energy savings, reduced harmonic distortion, and smaller installation footprint compared to four individual drives. This cabinet-level system is engineered for coordinated multi-axis applications in Saudi Arabia's oil and gas, mining, and heavy manufacturing sectors — specifically winder/unwinder pairs, multi-pump parallel arrays, coordinated conveyor trains, and crane hoist/traverse axes — where the ability to share regenerated braking energy across the common bus eliminates external braking resistors and recovers otherwise wasted energy back to the grid or to co-located motoring axes.

The CFW11MD's Active Front End (AFE) unit uses IGBT-based pulse-width modulation rectification to achieve total harmonic distortion of less than 5% at the point of common coupling, meeting IEEE 519-2014 harmonic limits without additional line-side filtering. The AFE also provides unity input power factor across the full load range, eliminating reactive power demand charges from SEC billing. Each inverter module within the cabinet supports independent speed and torque control modes — scalar, sensorless vector, or closed-loop vector — allowing mixed application types within the same cabinet. The DC bus design includes pre-charge circuitry, bus capacitor balancing, and individual inverter circuit breaker protection, complying with IEC 61800-5-1 and IEC 62477-1 safety standards for power drive systems.

In Saudi Arabia's industrial landscape, the CFW11MD finds its primary application in upstream oil and gas facilities operated by ARAMCO affiliates, where coordinated pump or compressor drives on a single switchboard reduce both CAPEX and the substation footprint at remote unmanned stations. SABIC and Ma'aden mining facilities operating conveyor systems with regenerative decline sections recover energy through the common bus, measurably reducing electricity costs reported in SEC invoices. The 50°C ambient design, combined with the AFE's ability to ride through voltage sags common on the Saudi industrial grid, gives plant operators confidence in continuous 24/7 operation without nuisance tripping. NEOM's planned automated port and logistics infrastructure represents a significant growth application for multi-drive coordinated motion systems of this type.

Razz Middle East offers the CFW11MD as a complete engineered solution: we perform the drive system sizing, design the cabinet layout, source and integrate all protection and control components, factory-test the assembled panel, and commission on-site. All engineering documentation — single-line drawings, protection coordination studies, and FAT test records — is provided in English and Arabic to satisfy ARAMCO, SABIC, and SEC project documentation requirements. Contact us for a detailed technical proposal and SAR budgetary pricing based on your motor count and power rating.
