محرك سيمنز SIMOTICS GP 1LE1 IE3 عالي الكفاءة
رقم الموديل: 1LE1002-1AB42-2AA4
Power Range: 0.09–315 kWVoltage: 380/660 V, 400/690 V (50 Hz)Efficiency Class: IE3 (IEC 60034-30-1)Enclosure: IP55 (IP65/IP66 optional)
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
محرك سيمنز SIMOTICS GP 1LE1 IE3 عالي الكفاءة — نظرة عامة
محرك SIMOTICS GP 1LE1 من سيمنز هو محرك حثي عام الاستخدام بكفاءة IE3 وإطار حديد زهر وحماية IP55 وعزل Class F يغطي 0.09 إلى 315 كيلوواط. نسخة Converter-Duty مُحسَّنة للاستخدام مع محركات SINAMICS.
يُستخدم في جميع أنواع التطبيقات الصناعية في المملكة ومطلوب بكفاءة IE3 وفق SEEP. توفر راز الشرق الأوسط 1LE1 من جميع أحجام IEC.
المواصفات الفنية
المواصفات الكاملة لـ 1LE1002-1AB42-2AA4
- Power Range
- 0.09–315 kW
- Voltage
- 380/660 V, 400/690 V (50 Hz)
- Efficiency Class
- IE3 (IEC 60034-30-1)
- Enclosure
- IP55 (IP65/IP66 optional)
- Insulation
- Class F, Class B temperature rise
- Mounting
- B3, B5, B35, V1
- Ambient
- -20 to +40°C standard (+60°C high-ambient option)
- Cooling
- TEFC (IC411)
- Standard
- IEC 60034
المميزات والفوائد
- IE3 premium efficiency class per IEC 60034-30-1 reduces motor energy consumption by 1–3% versus IE2, meeting Saudi Energy Efficiency Program (SEEP) IE3 minimum efficiency requirements for new industrial motor installations.
- Class F insulation with Class B temperature rise provides a 25°C thermal headroom margin, extending insulation life and providing additional protection against intermittent overloading in high-ambient Saudi environments.
- IP55 ingress protection seals motor internals against dust and water jets, enabling outdoor installation at pump stations and process areas across Saudi Arabia without additional housing.
- High-ambient-temperature variant rated up to +60°C maintains full rated output in outdoor Saudi summer conditions where standard motors require derating.
- Converter-duty (CD) variant with reinforced winding insulation, external cooling fan, and insulated bearings is optimised for SINAMICS G120/G150 VFD operation — required by ARAMCO Engineering Standards for all motor-drive packages.
- Pre-greased sealed bearings in IEC 80–180 frames provide maintenance-free bearing operation for up to 20,000 hours, reducing maintenance on continuously-operating motor installations.
- IEC standard frame dimensions ensure mechanical interchangeability with motors from other manufacturers, allowing 1LE1 to directly replace competitor motors without baseplate or coupling modifications.
التطبيقات الصناعية
- Centrifugal pump drives at NWC water pumping stations, SWCC desalination facilities, and ARAMCO utility water systems, where IE3 efficiency and IP55 sealing satisfy SEEP requirements and outdoor installation conditions.
- HVAC air handling unit, cooling tower, and chilled water pump motor drives in commercial buildings and industrial facilities, where IE3 reduces facility energy consumption and satisfies SEC large-consumer reporting.
- Conveyor and material handling system motors at cement plants and quarrying operations, where cast iron frame robustness and IP55 sealing provide reliable performance in dusty outdoor environments.
- SINAMICS G120-driven motor-drive packages at SABIC and ARAMCO process facilities, where converter-duty 1LE1 motors satisfy ARAMCO Engineering Standards for VFD-connected motors.
- Fan drives in industrial ventilation, HVAC, and process cooling, where the high-ambient rating maintains full airflow delivery during Saudi Arabia's 45–50°C summer peak demand periods.
- Compressor motor drives at industrial utility systems, where the 1LE1's cast iron frame and Class F insulation withstand continuous heavy-duty operation cycles.
- Irrigation and agricultural pump drives in Qassim, Al-Ahsa, and Tabuk regions, where IE3 efficiency reduces energy costs at high-running-hour sites.
