جهاز التيار المتبقي سيمنز 5SV
رقم الموديل: 5SV3342-6
Rated Current: 25–125 ASensitivity: 10 mA / 30 mA / 100 mA / 300 mACurrent Types: AC (sinusoidal) / A (pulsating DC) / F (high frequency)Voltage: 230/400 V AC
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
جهاز التيار المتبقي سيمنز 5SV — نظرة عامة
جهاز التيار المتبقي سيمنز 5SV يحمي من الصدمة الكهربائية وخطر الحريق من خلال تيارات 10 إلى 300 مللي أمبير بثلاثة أنواع: AC وA وF للأحمال الإلكترونية ومحركات السرعة المتغيرة ومعدات الشحن.
يُستخدم في التركيبات السكنية والتجارية والصناعية في المملكة العربية السعودية وفق متطلبات الكود السعودي للبناء. توفر راز الشرق الأوسط 5SV من جميع التحسسات والأنواع.
المواصفات الفنية
المواصفات الكاملة لـ 5SV3342-6
- Rated Current
- 25–125 A
- Sensitivity
- 10 mA / 30 mA / 100 mA / 300 mA
- Current Types
- AC (sinusoidal) / A (pulsating DC) / F (high frequency)
- Voltage
- 230/400 V AC
- Poles
- 2P / 4P
- Response Time
- <300 ms (general), <40 ms (S-type selective)
- Mounting
- DIN rail TS35
- Standard
- IEC 61008-1
المميزات والفوائد
- Three current type variants — AC, A, and F — cover all earth leakage waveform types from simple sinusoidal faults through pulsating DC from electronic equipment to high-frequency leakage from switched-mode power supplies and three-phase VFDs.
- 30 mA sensitivity level provides personal shock protection at the IEC 60479 threshold for cardiac fibrillation, satisfying Saudi Building Code requirements for socket outlet and bathroom circuit protection in residential and commercial buildings.
- High immunity to nuisance tripping from transient earth leakage associated with motor starting, capacitor discharge equipment, and electronic load switching reduces operational disruptions in facilities where false trips cause safety or production risks.
- Type A devices protect circuits with variable speed drives, LED lighting, EV charging equipment, and other electronics that produce pulsating DC leakage currents undetectable by conventional Type AC RCCBs.
- Selective (S-type) variants with 40–200 ms intentional response delay allow upstream-downstream protection coordination between main RCCB and branch RCCBs, isolating only the faulted circuit rather than de-energising the entire distribution board.
- Test button functional verification can be performed with the circuit energised and loaded, allowing regular safety testing per IEC 61008 recommendations without requiring circuit shutdown or load disconnection.
- 2P configuration for single-phase circuits and 4P configuration for three-phase circuits from the same product series simplify procurement and stocking for panel builders assembling mixed single-phase and three-phase distribution boards.
التطبيقات الصناعية
- Residential villa and apartment socket outlet circuit protection in Saudi Arabia's major housing developments, where Type A 30 mA 5SV RCCBs address the increasing density of VFDs, LED drivers, and EV chargers producing pulsating DC leakage.
- Bathroom, kitchen, and outdoor circuit RCD protection in commercial buildings and hotels, where 30 mA sensitivity satisfies Saudi Building Code mandatory RCD requirements for circuits in areas with water or moisture presence.
- EV charging point circuit protection in commercial car parks and residential compounds, where Type A 5SV devices detect the DC leakage currents produced by EV on-board chargers that conventional Type AC devices cannot monitor.
- Hospital patient care area circuit protection, where 10 mA sensitivity satisfies IEC 60364-7-710 requirements for medical locations where patients with reduced electrical resistance (via medical equipment) face elevated shock risk.
- Data centre and server room distribution board protection, where Type F 5SV devices handle high-frequency leakage from UPS systems and switched-mode power supply banks without nuisance tripping that would cause IT service disruption.
- Industrial facility welfare and canteen area protection at petrochemical and manufacturing sites, where mandatory RCD protection on kitchen equipment circuits satisfies ARAMCO and SABIC site electrical safety management requirements.
- Commercial kitchen and restaurant circuit protection in hotels and food service establishments across the Kingdom, where 30 mA Type A protection addresses the mixed conventional and variable-speed equipment loads on kitchen distribution boards.
مورد معتمد في المملكة العربية السعودية
احصل على عرض سعر لـ جهاز التيار المتبقي سيمنز 5SV
نرد خلال 4 ساعات. أرسل رقم الموديل 5SV3342-6 للحصول على سعر تنافسي مع التسليم في أنحاء المملكة العربية السعودية والخليج.
أسئلة شائعة حول جهاز التيار المتبقي سيمنز 5SV
أكثر الأسئلة شيوعاً من العملاء في المملكة العربية السعودية
