لوحة وحدة استهلاك سيمنز 5SY MCB + 5SV RCD
رقم الموديل: 5SY6116-7+5SV3612-6
MCB Type: 5SL (5SY) series, B and C trip characteristicsRCCB Type: 5SV Type A (30 mA standard, 10/100/300 mA options)Circuit Ways: 4, 8, 12, 16, 20, 24-way configurationsVoltage: 230/400 V AC
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
لوحة وحدة استهلاك سيمنز 5SY MCB + 5SV RCD — نظرة عامة
لوحة وحدة الاستهلاك من سيمنز تجمع قواطع 5SY MCB وأجهزة 5SV RCCB في تجميع حماية منسق مسبق التوصيل والاختبار للمنازل والمباني التجارية. تُجمَّع بـ 4 إلى 24 دائرة بمنحنيات B/C وRCCB من النوع A أو F بحساسية 30 مللي أمبير.
معيار قياسي في مشاريع NHC وROSHN والتطوير التجاري في المملكة. تُجمِّع راز الشرق الأوسط اللوحات وتختبرها وتُسلِّمها جاهزة للتركيب.
المواصفات الفنية
المواصفات الكاملة لـ 5SY6116-7+5SV3612-6
- MCB Type
- 5SL (5SY) series, B and C trip characteristics
- RCCB Type
- 5SV Type A (30 mA standard, 10/100/300 mA options)
- Circuit Ways
- 4, 8, 12, 16, 20, 24-way configurations
- Voltage
- 230/400 V AC
- Breaking Capacity
- 6 kA (5SL4) / 10 kA (5SL6)
- Board Enclosure
- Siemens flush-mount or surface-mount distribution board
- Coordination
- Tested and verified per IEC 61009-1
- Assembly
- Pre-wired and tested by Razz Middle East
المميزات والفوائد
- Verified coordination between 5SY MCBs and 5SV RCCBs using Siemens tested I²t tables confirms upstream RCCB integrity after downstream MCB fault operation — coordination data unavailable when mixing brands from different manufacturers.
- Type A RCCB protection detects both sinusoidal and pulsating DC earth leakage currents produced by LED lighting drivers, VFDs, and EV charging equipment increasingly standard in Saudi residential and commercial buildings.
- 30 mA RCCB sensitivity provides personal shock protection at the IEC 60479 cardiac fibrillation threshold, satisfying Saudi Building Code mandatory RCD requirements for bathroom, kitchen, outdoor, and all socket outlet circuits.
- Pre-assembly and testing by Razz Middle East eliminates on-site panel wiring errors, reduces electrical contractor site installation time, and delivers a tested and labelled board ready for SASO electrical inspection without on-site assembly verification.
- Custom configuration from 4-way to 24-way with customer-specified circuit labelling, B or C curve MCB selection, and Type A or Type F RCCB selection provides a tailored board matching the building's specific circuit layout from a single order.
- SASO-approved 5SL MCB and 5SV RCCB products ensure Saudi Standards Authority inspection compliance without additional certification documentation for building handover and occupancy approval.
- Same-manufacturer MCB and RCCB selection simplifies post-installation technical support, warranty resolution, and spare component sourcing from Razz Middle East's local stock compared to split-brand boards requiring two suppliers for maintenance.
التطبيقات الصناعية
- Residential villa consumer unit final circuit protection for NHC and ROSHN housing megaproject developments across Saudi Arabia, where pre-assembled tested boards accelerate electrical installation and SASO inspection timescales.
- Apartment tower distribution board final circuit protection in Jeddah waterfront and Riyadh northern district residential developments, where Type A 30 mA RCCB satisfies Saudi Building Code mandatory earth fault protection requirements.
- Commercial retail and F&B tenant fit-out distribution boards in shopping malls across the Kingdom, where pre-assembled boards reduce fit-out contractor installation time and provide verified protection coordination documentation for mall operator approval.
- Red Sea Project resort villa and hotel room distribution boards, where Siemens pre-assembled boards deliver consistent brand quality and SASO compliance across all accommodation units in the resort portfolio.
- NEOM Sindalah Island and The Line residential distribution boards, where pre-assembled tested boards satisfy the projects' quality management system requirements for electrical installation documentation and material traceability.
- Hotel guestroom and corridor distribution panels for major hotel developments in Makkah and Madinah, where pre-assembled boards reduce installation time during the critical construction phases of Holy Cities hospitality projects.
- Light industrial unit and small workshop distribution boards in MODON industrial estates, where C-curve MCBs on motor and HVAC circuits and B-curve on lighting and socket circuits provide correct protection without on-site curve selection errors.
