مفتاح قطع الحمل المعياري سيمنز 5ST3
رقم الموديل: 5ST3014
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
مفتاح قطع الحمل المعياري سيمنز 5ST3 — نظرة عامة
مفتاح قطع الحمل المعياري سيمنز 5ST3 للتيارات حتى 125 أمبير بفئات الاستخدام AC-22A وAC-23A. متوفر بتكوينات 1 إلى 4 أقطاب مع مقبض مرئي للتشغيل/الإيقاف وخيار تأمين بالقفل لإجراءات LOTO.
يُستخدم في لوحات التوزيع التجارية والصناعية والسكنية في المملكة. توفر راز الشرق الأوسط هذه المفاتيح مع خدمات تجميع لوحات التوزيع.
المواصفات الفنية
المواصفات الكاملة لـ 5ST3014
- Rated Current
- 25–125 A
- Voltage
- 400 V AC
- Poles
- 1P, 2P, 3P, 4P
- Utilisation
- AC-22A (resistive), AC-23A (motor)
- Mounting
- DIN rail 35 mm, 2 modules per pole
- Handle
- Toggle-rotary, ON/OFF colour marking
- Padlock
- Optional in OFF position
- Short-Circuit
- 6 kA (with upstream MCB/fuse)
- Compliance
- IEC 60947-3, CE
المميزات والفوائد
- AC-23A motor load utilisation category allows switching of motor-circuit currents at rated current, making the 5ST3 suitable as a per-motor circuit isolator in sub-distribution panels feeding motor control circuits.
- Toggle-rotary handle with clear ON/OFF colour marking provides immediately visible isolation status from the panel front — a key requirement for Saudi MEW electrical inspection compliance.
- Optional padlock attachment in OFF allows LOTO procedures at individual circuit level, enabling multi-trade teams to apply personal locks on specific circuits without isolating the entire board.
- 1P through 4P configurations in a common module width cover every circuit requirement in Saudi distribution board designs, from single-phase lighting to three-phase motor sub-distribution.
- DIN rail 35 mm 2-module-per-pole format integrates into standard IEC 61439-3 enclosures alongside 5SY MCBs and 5SV RCCBs without special modifications.
- 6 kA short-circuit coordination with upstream MCBs and fuses ensures the 5ST3 withstands prospective fault currents at distribution board level in Saudi commercial and light industrial installations.
- Compact design and competitive pricing make the 5ST3 the default per-circuit isolator for Saudi panel builders assembling MDB and SDB boards for residential and commercial projects across the Kingdom.
التطبيقات الصناعية
- Per-circuit isolation in commercial building sub-distribution boards across Saudi commercial towers and government buildings, where individual circuit isolation points satisfy Saudi Electrical Regulations (SER) maintenance requirements.
- Motor circuit isolation in sub-distribution panels feeding pump, fan, and conveyor starters, where AC-23A rating ensures reliable switching of motor circuits during industrial maintenance.
- Residential villa consumer unit main switch in MEW-approved enclosures, providing the visible isolation point required by Saudi building inspection authorities for each villa distribution board.
- HVAC equipment sub-distribution isolation for AHUs, FCUs, and chiller auxiliaries in commercial buildings, where padlock option supports HVAC maintenance safety procedures.
- Retail shop board circuit isolation at shopping centres in Riyadh, Jeddah, and Dammam, allowing maintenance of individual tenant circuits without disturbing adjacent tenants.
- Light industrial workshop per-machine circuit isolation, satisfying the IEC 60204-1 requirement for a local isolation means adjacent to each piece of production equipment.
- Panel builder component supply for domestic and export panels in Saudi MODON industrial zones, where the 5ST3's availability, competitive pricing, and brand recognition facilitate OEM machine panel cost optimisation.
