محرك سيمنز SIMOTICS XP 1LE5 ATEX للمناطق الخطرة
رقم الموديل: 1LE5003-1AB42-1FB4
Power Range: 0.25–355 kWVoltage: 380/660 V, 400/690 V (50 Hz)Explosion Protection: Ex d (flameproof) IIB/IIC, Ex e (increased safety) IICertification: ATEX and IECEx dual-certified
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
محرك سيمنز SIMOTICS XP 1LE5 ATEX للمناطق الخطرة — نظرة عامة
محرك SIMOTICS XP 1LE5 من سيمنز هو محرك انفجاري معتمد ATEX/IECEx للمناطق الخطرة Zone 1/2 بمفهومي Ex d وEx e من 0.25 إلى 355 كيلوواط لمجموعات الغاز IIA وIIB وIIC.
يُستخدم في منشآت ARAMCO وSABIC والمنشآت البحرية وقطاع التعدين في المملكة. توفر راز الشرق الأوسط 1LE5 مع جميع وثائق شهادة ATEX وIECEx.
المواصفات الفنية
المواصفات الكاملة لـ 1LE5003-1AB42-1FB4
- Power Range
- 0.25–355 kW
- Voltage
- 380/660 V, 400/690 V (50 Hz)
- Explosion Protection
- Ex d (flameproof) IIB/IIC, Ex e (increased safety) II
- Certification
- ATEX and IECEx dual-certified
- Zones
- Zone 1 and Zone 2
- Gas Groups
- IIA, IIB, IIC (Ex d)
- Temperature Class
- T1–T6
- Enclosure
- IP55 / IP65
المميزات والفوائد
- ATEX and IECEx dual certification satisfies both EU (ATEX Directive 2014/34/EU) and international (IECEx scheme) requirements from a single motor certificate, meeting ARAMCO and SABIC procurement specifications.
- Flameproof (Ex d) with precision-machined joint gaps contains internal explosions within the motor housing for all gas groups including Group IIC (hydrogen, acetylene) at ARAMCO LPG and hydrogen processing facilities.
- Increased-safety (Ex e) eliminates ignition sources through enhanced insulation and rotor design, providing Zone 1 protection in a smaller and lighter motor than equivalent Ex d motors.
- Gas group IIC flameproof (Ex d IIC) variant provides protection against the most ignitable industrial gases — hydrogen, acetylene — present at ARAMCO LPG, hydrogen, and acetylene handling areas.
- Temperature class range T1–T6 allows motor surface temperature to be matched to the auto-ignition temperature of the specific process gas in the hazardous area.
- Converter-duty ATEX variant with reinforced winding insulation and insulated bearings for VFD-fed operation satisfies IEC 60079-7 enhanced safety requirements for frequency converter-fed Ex e motors.
- High-ambient-temperature variants rated up to +55°C maintain full rated output in Saudi Arabia's Gulf coast and desert process plant environments without motor derating during peak summer operation.
التطبيقات الصناعية
- ARAMCO crude oil and gas process pump motors at upstream and downstream facilities in the Eastern Province, where ATEX Zone 1 Ex d or Ex e certification and ARAMCO Engineering Standard documentation are mandatory.
- SABIC Jubail petrochemical plant pump, fan, and agitator motors in classified Zone 1 and Zone 2 process areas, where dual ATEX/IECEx certificates satisfy the project's ATEX equipment register.
- Ma'aden mining facility Zone 2 classified areas, where 1LE5 Ex e motors drive conveyors, fans, and pumps in areas with potential dust and gas hazards.
- ARAMCO offshore platform pump, compressor, and ventilation fan motors, where IP65 sealing and IIB/IIC gas group coverage satisfies both offshore corrosive environment and hydrocarbon atmosphere requirements.
- Saudi Aramco LPG and gas fractionation facility motors in Zone 1 areas classified for Group IIC gases, where only flameproof Ex d IIC certified motors satisfy the hazard classification.
- SINAMICS G120D decentralised drive packages in Zone 2 industrial areas, where converter-duty 1LE5 ATEX motors paired with Zone 2-certified drive enclosures create a complete VFD-motor solution.
- Chemical and industrial gas processing facility motors, where IECEx international certification satisfies Saudi chemical plant operator inspection and insurance standards.
مورد معتمد في المملكة العربية السعودية
احصل على عرض سعر لـ محرك سيمنز SIMOTICS XP 1LE5 ATEX للمناطق الخطرة
نرد خلال 4 ساعات. أرسل رقم الموديل 1LE5003-1AB42-1FB4 للحصول على سعر تنافسي مع التسليم في أنحاء المملكة العربية السعودية والخليج.
