نظام قضبان التوزيع SENTRON 8PQ من سيمنز
رقم الموديل: 8PQ3212-0BA10
Rated Current: 100–6300 ASystem Voltage: Up to 690 V AC, 50/60 HzShort-Circuit Rating: Up to 80 kA (1 s)Enclosure: IP55 aluminium housing
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
نظام قضبان التوزيع SENTRON 8PQ من سيمنز — نظرة عامة
نظام قضبان التوزيع SENTRON 8PQ من سيمنز هو نظام توزيع طاقة جاهز من المصنع يغطي التيارات من 100 إلى 6300 أمبير بحماية IP55 وتحمل قصر دائرة حتى 80 كيلوأمبير. يتيح وحدات إيقاف قابلة للتوصيل عند أي فترة 250 ملم لتوزيع الأحمال المرن.
يُستخدم في مراكز البيانات والمباني التجارية الشاهقة والمستشفيات في المملكة العربية السعودية. توفر راز الشرق الأوسط التصميم الكامل والتوريد والإشراف على التركيب.
المواصفات الفنية
المواصفات الكاملة لـ 8PQ3212-0BA10
- Rated Current
- 100–6300 A
- System Voltage
- Up to 690 V AC, 50/60 Hz
- Short-Circuit Rating
- Up to 80 kA (1 s)
- Enclosure
- IP55 aluminium housing
- Conductors
- Aluminium or copper (3P+N+PE)
- Tap-Off Grid
- Every 250 mm
- Straight Section Length
- 1.5 m, 2 m, 3 m standard
- Fire Performance
- IEC 60332-3 (optional)
- Compliance
- IEC 61439-6, type tested
- Ambient
- -5 to +50°C operating
المميزات والفوائد
- Factory-assembled type-tested construction eliminates site jointing variability, providing consistent electrical resistance along the distribution run and guaranteed short-circuit withstand — advantages that site-assembled cable systems cannot replicate.
- Plug-in tap-off units at every 250 mm interval allow individual circuit breakers (up to 630 A) to be inserted at any point along the busbar run, with the ability to add or relocate tap-offs under live conditions to accommodate load changes.
- IP55 fully enclosed aluminium housing provides better mechanical protection than open cable trunking, withstands jet cleaning in food and beverage plant environments, and eliminates the fire propagation risk of exposed cable bundles.
- Rated current from 100 A to 6300 A in a common modular system allows a single product family to serve small commercial sub-distribution risers up to the main power spines of the Kingdom's largest hyperscale data centres.
- Aluminium conductor option reduces busbar system weight by up to 40% compared to copper equivalents, simplifying structural support design in high-rise buildings and reducing the load on suspended ceiling systems in data centres.
- 250 mm modular grid of tap-off positions provides the flexibility required by data centre operators to respond to tenant power demand changes without infrastructure replacement — a key Total Cost of Ownership benefit.
- IEC 61439-6 type testing at accredited laboratories provides the certified short-circuit withstand and temperature-rise data required for Saudi project specification compliance and SEC switchgear approval documentation.
التطبيقات الصناعية
- Data centre main power distribution spines at hyperscale and colocation facilities in Riyadh's Digital Mile and NEOM tech district, where 3200–6300 A busbar risers distribute UPS output to server floor PDUs with tap-off flexibility for evolving rack layouts.
- Commercial high-rise building power distribution risers at King Abdullah Financial District and Jeddah Central towers, where 1600–3200 A 8PQ systems carry power from basement MSBs to floor distribution boards more efficiently than parallel cable routes.
- Hospital main power distribution arteries at new Ministry of Health facilities across Saudi Arabia, where the IP55 sealed system provides the hygiene and mechanical robustness required in clinical environments near sterilisation and theatre areas.
- Industrial manufacturing floor power distribution at SABIC and IKTVA plastics and chemicals plants, where plug-in tap-offs allow machine layout changes to be accommodated without rewiring the distribution infrastructure.
- Airport terminal power distribution at King Khalid International Airport Riyadh and Dammam expansion projects, where large current distribution across long terminal buildings favours busbar over multi-cable alternatives.
- Petrochemical plant main substation LV distribution from switchgear to MCC rooms, where the 8PQ's 80 kA fault withstand rating matches the high prospective fault currents at generator-backed industrial substations.
- NEOM city infrastructure power distribution for Sindalah island and The Line modules, where the modular reconfigurability of the 8PQ BTS supports the phased construction and evolving load layout of mega-project development zones.
