ريلاي مراقبة الجهد والطور سيمنز SIRIUS 3UG
رقم الموديل: 3UG4622-1AW30
Monitoring: Phase failure, phase sequence, asymmetry (>10%), overvoltage, undervoltageVoltage: 200–480 V AC (3-phase direct connection)Response Time: 2–20 s (adjustable)Trip Thresholds: Overvoltage and undervoltage adjustable by pot
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
ريلاي مراقبة الجهد والطور سيمنز SIRIUS 3UG — نظرة عامة
ريلاي مراقبة الجهد والطور SIRIUS 3UG من سيمنز يراقب خمس حالات للمورد الثلاثي في آن واحد: فشل الطور وخطأ التسلسل وعدم التماثل والجهد العالي والمنخفض بتوصيل مباشر بدون محولات.
يُستخدم كحماية قياسية للمحركات الصناعية في لوحات التحكم في المملكة. توفر راز الشرق الأوسط 3UG من المخزون المحلي.
المواصفات الفنية
المواصفات الكاملة لـ 3UG4622-1AW30
- Monitoring
- Phase failure, phase sequence, asymmetry (>10%), overvoltage, undervoltage
- Voltage
- 200–480 V AC (3-phase direct connection)
- Response Time
- 2–20 s (adjustable)
- Trip Thresholds
- Overvoltage and undervoltage adjustable by pot
- Output
- 1 changeover contact (5 A, 250 V AC)
- Mounting
- DIN rail 22.5 mm
- Supply
- Measured from monitored circuit
- Standard
- IEC 60255
المميزات والفوائد
- Five-function protection in one device — phase failure, sequence, asymmetry, overvoltage, undervoltage — replaces five separate monitoring relays with a single 22.5 mm DIN-rail device, reducing panel space and wiring.
- Phase failure detection within 2–4 seconds of single-phasing provides a critical final protection layer before the thermal overload relay trips, preventing motor burnout in the most common supply-side failure mode.
- Phase reversal detection prevents damage from reversed motor rotation after maintenance reconnection or transformer replacement, catching connection errors before pumps run backwards.
- Direct three-phase supply connection — no CT or VT required — makes installation as simple as connecting supply wires and adjusting two threshold pots, achievable by any qualified electrician.
- Adjustable response time (2–20 seconds) prevents nuisance tripping during momentary supply disturbances such as motor starting voltage dips while still protecting against sustained phase failure.
- Asymmetry detection at >10% phase voltage imbalance identifies deteriorating supply conditions before imbalance causes excessive negative-sequence heating in motors.
- Single changeover output contact rated 5 A, 250 V AC directly interrupts the motor starter's control circuit or activates an alarm without additional interface relays.
التطبيقات الصناعية
- Three-phase motor protection in industrial motor starter panels across ARAMCO, SABIC, and NWC facilities, providing supply quality protection in addition to the thermal overload relay's load-current protection.
- Pump motor protection in water booster stations and irrigation pump panels, where phase failure detection prevents undetected single-phasing at unmanned remote pump stations.
- HVAC chiller and air handling unit motor protection in commercial buildings, where phase reversal detection catches reconnection errors after equipment maintenance.
- Industrial compressor motor protection at manufacturing facilities, where asymmetry detection identifies deteriorating supply quality before motor insulation damage accumulates.
- Generator output monitoring in standby power systems, where the 3UG verifies generator output voltage, phase sequence, and balance before the transfer switch connects the generator to the critical load bus.
- Supply quality monitoring at oil field pump station motor control panels in remote desert locations, where simple two-pot commissioning allows field technicians to set up monitoring without specialist equipment.
- Transformer secondary supply monitoring in industrial substation distribution boards, where asymmetry detection identifies unequal single-phase loading causing transformer neutral current and overheating.
