قاطع سيمنز SENTRON 3VL المقولب
رقم الموديل: 3VL3725-2DC36-0AA0
Rated Current: 100–1600 AVoltage: Up to 690 V ACBreaking Capacity: Up to 100 kA at 400 VPoles: 3P / 4P
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
قاطع سيمنز SENTRON 3VL المقولب — نظرة عامة
قاطع SENTRON 3VL من سيمنز يغطي 100 إلى 1600 أمبير بقدرة قطع 100 كيلو أمبير بنسختين TM وETU بإطار مقوى للتطبيقات الصناعية الصعبة.
يُستخدم في لوحات التوزيع الثانوية في المنشآت الصناعية والتجارية في المملكة. توفر راز الشرق الأوسط 3VL من جميع التيارات.
المواصفات الفنية
المواصفات الكاملة لـ 3VL3725-2DC36-0AA0
- Rated Current
- 100–1600 A
- Voltage
- Up to 690 V AC
- Breaking Capacity
- Up to 100 kA at 400 V
- Poles
- 3P / 4P
- Trip Unit
- TM (thermal-magnetic) / ETU (electronic, adjustable L/S/I/G)
- Mounting
- Fixed
- Current Limiting
- 3VL1 version available
- Standard
- IEC 60947-2
المميزات والفوائد
- Thermal-magnetic (TM) version provides factory-calibrated, maintenance-free overcurrent protection for straightforward sub-distribution applications where adjustable settings and digital communication are not required.
- Electronic trip unit (ETU) with adjustable L, S, I, and G thresholds enables precise protection coordination in multi-level distribution hierarchies, replacing fixed TM curves with optimised system-matched settings.
- Current-limiting 3VL1 limits peak fault current significantly below the prospective level, reducing required fault current ratings of downstream switchgear, cables, and transformers in system design.
- Reinforced housing and contact system for industrial vibration and shock levels provides greater mechanical robustness than standard MCCBs in motor control, generator protection, and mobile distribution applications.
- Breaking capacity up to 100 kA covers fault current levels encountered at LV busbars close to large industrial power transformers in Saudi petrochemical and utility distribution systems.
- 4-pole configuration with switchable neutral provides complete isolation of all conductors including neutral in TN-C-S distribution systems required by IEC 60364 for certain industrial facility distribution configurations.
- Wide accessory range including undervoltage release, shunt release, auxiliary contacts, and alarm contacts allows remote switching, fault signalling, and interlocking without additional relay modules.
التطبيقات الصناعية
- Sub-distribution board main and outgoing protection in MODON industrial estate manufacturing facilities, where 3VL TM breakers provide reliable overcurrent protection at competitive cost.
- Oil & gas facility site distribution board protection at ARAMCO temporary and permanent construction projects, where 3VL robustness handles mechanical stresses of mobile power distribution equipment.
- Generator protection and output switching at Saudi industrial facility standby power systems, where the 3VL's breaking capacity handles generator fault contribution and the TM curve accommodates the short-circuit characteristic.
- Motor feeder protection in existing Saudi industrial MCCs where mechanical robustness above that of standard MCBs is required for motor feeders above 100 A.
- Construction site distribution board protection for major Saudi Vision 2030 construction projects, where 3VL's robust construction handles rough handling of temporary site electrical equipment.
- Commercial building sub-distribution panel main breakers, where the 3VL's compact size versus ACBs reduces panel dimensions while maintaining breaking capacity needed near main substations.
- Coordinated distribution hierarchy with 3WL or 3VA main breakers and 3VL sub-distribution breakers in industrial LV switchboards, achieving selective fault isolation per IEC 60947.
