ملحقات لوحة التوزيع ALPHA 160 من سيمنز
رقم الموديل: 5SG7150
Enclosure Modules: 12–48 module (flush and surface)DIN Rail: 35 mm TS35, cut to lengthNeutral Bars: 15–20 connection capacityEarth Bars: DIN-rail mount, 15–20 connections
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
ملحقات لوحة التوزيع ALPHA 160 من سيمنز — نظرة عامة
لوحة ALPHA 160 وملحقاتها من سيمنز توفر نظاماً معتمداً بموجب IEC 61439-3 لتجميع لوحات التوزيع السكنية والتجارية. تشمل علب مدمجة وسطحية من 12 إلى 48 وحدة وقضبان DIN وألواح توزيع وأشرطة توزيع ذات باب مزدوج شفاف.
تُعد المعيار السائد للوحات توزيع المساكن في المملكة. توفر راز الشرق الأوسط مجموعة الملحقات الكاملة مع لوحات مجمعة ومختبرة للمطورين العقاريين.
المواصفات الفنية
المواصفات الكاملة لـ 5SG7150
- Enclosure Modules
- 12–48 module (flush and surface)
- DIN Rail
- 35 mm TS35, cut to length
- Neutral Bars
- 15–20 connection capacity
- Earth Bars
- DIN-rail mount, 15–20 connections
- Busbar
- 3-module, 80A, 3-phase + N
- Material
- ABS plastic enclosure, galvanised DIN rail
- IP Rating
- IP30 (door closed) / IP40 option
- Compliance
- IEC 61439-3, SASO 60364, CE
المميزات والفوائد
- Dual-door design with transparent inner window allows circuit labels and breaker tripped status to be identified without opening the live enclosure — satisfying the Saudi MEW inspection requirement for visible circuit identification.
- Complete IEC 61439-3 certified system from a single manufacturer ensures mechanical and electrical compatibility between enclosures, DIN rail, busbars, and terminal bars without improvisation or substitution risks.
- Flush and surface mount variants in the same product family allow the same ALPHA 160 enclosure to be specified for both recessed wall installation in finished residential interiors and surface mounting in utility and plant rooms.
- 3-module DIN rail busbar (5SG7150) distributes phase power to rows of 5SY MCBs without individual wiring connections, accelerating assembly and reducing the risk of wiring errors in multi-circuit consumer units.
- 12 to 48 module capacity covers every residential villa, apartment, and commercial shop distribution board size encountered in Saudi building projects, eliminating the need to source enclosures from multiple product families.
- Compatible with the complete Siemens 5SY MCB, 5SV RCCB, 5SM RCBO, and 5ST3 load break switch range — enabling a single-manufacturer distribution board specification that simplifies procurement and guarantees type-tested co-ordination.
- Arabic and English dual-language circuit label holders supplied with the enclosure allow compliant bilingual circuit identification as required by Saudi MEW consumer installation regulations for all distribution boards.
التطبيقات الصناعية
- Residential villa main consumer unit in flush-mount wall installation across Saudi Arabia's private villa sector in Riyadh, Jeddah, Al Khobar, and Dammam, providing MEW-compliant circuit identification and inspection access.
- Apartment building sub-distribution boards for multi-storey residential developments in major Saudi cities, where surface-mount ALPHA 160 enclosures in meter rooms serve individual apartment tenant circuits.
- Commercial retail shop distribution boards in Saudi shopping centres and commercial strips, where the ALPHA 160's professional appearance and transparent inner door satisfy MEW electrical inspection requirements.
- Light industrial workshop consumer units in MODON small industrial units, where the wider module capacity (36–48 modules) accommodates the mix of power and lighting circuits common in light manufacturing premises.
- Government and institutional building sub-distribution boards, where Saudi SASO-compliant IEC 61439-3 certification of the ALPHA 160 satisfies the tender specification requirements of MOMRA and SEC project specifications.
- Hotel room distribution boards and corridor junction boards at Saudi hospitality projects, where the flush-mount aesthetic of the ALPHA 160 integrates with finished interior design without exposed conduit or surface trunking.
- Temporary site compound electrical installations for construction projects, where the surface-mount ALPHA 160 provides a compliant, quickly assembled distribution board for contractor accommodation and site offices.
