siemens
لوحة HMI الأساسية SIMATIC KTP900 من سيمنز
رقم الموديل: 6AV2123-2JB03-0AX0
Display: 9" TFT 800×480 pixels, 65,536 coloursFunction Keys: 8 configurable hardware keysTouchscreen: Resistive (glove-operable)Communication: PROFINET (RJ45 Ethernet)
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
لوحة HMI الأساسية SIMATIC KTP900 من سيمنز — نظرة عامة
لوحة SIMATIC KTP900 Basic من سيمنز هي لوحة HMI بشاشة لمس 9 بوصة و8 مفاتيح وظيفية للتصور الفعال من حيث التكلفة. مبرمجة بالكامل ضمن TIA Portal مع وحدات SIMATIC S7، مما يتيح مشاركة العلامات والإنذارات وتناسق المشروع.
تُستخدم على نطاق واسع في آلات التعبئة والتغليف ولوحات التحكم في المضخات وأجهزة تحكم HVAC في المملكة العربية السعودية. توفر راز الشرق الأوسط برمجة HMI ثنائية اللغة (عربي/إنجليزي) مع دعم تقني محلي.
المواصفات الفنية
المواصفات الكاملة لـ 6AV2123-2JB03-0AX0
- Display
- 9" TFT 800×480 pixels, 65,536 colours
- Function Keys
- 8 configurable hardware keys
- Touchscreen
- Resistive (glove-operable)
- Communication
- PROFINET (RJ45 Ethernet)
- User Memory
- 1 MB screen/tag data
- Operating Temp
- 0 to +50°C
- Front Protection
- IP65
- Software
- TIA Portal WinCC Basic V17+
- Languages
- Unicode multilingual support
- Compliance
- CE, UL 508
المميزات والفوائد
- TIA Portal WinCC Basic integration provides shared tag database with S7-1200/1500 PLCs — changes to PLC tags automatically propagate to HMI screens, eliminating manual data synchronisation and reducing project engineering time by up to 40%.
- Eight configurable hardware function keys provide reliable tactile input in industrial environments where operator gloves, wet hands, or high-vibration conditions make touchscreen-only operation unreliable — critical for Saudi heavy industry and offshore applications.
- PROFINET communication with all SIMATIC S7 PLC generations plus Modbus TCP OPC proxy connectivity allows the KTP900 Basic to serve as the operator panel for legacy S7-300/400 systems being extended with new panels.
- IP65 front-face protection seals the panel face against dust ingress and water jet cleaning — meeting the minimum protection requirement for installation in Saudi Arabia's HVAC plant rooms, pump stations, and light industrial machinery.
- Unicode multilingual font engine supports full Arabic script display with right-to-left text formatting, allowing screen text to be developed in both Arabic and English within the same TIA Portal HMI project for bilingual operator panels.
- Compact 228×163 mm panel cutout and 46 mm depth allow the KTP900 Basic to be installed in standard 300×300 mm panel door cutouts that are the norm in Saudi Arabia's machine builder market, minimising cabinet modifications.
- 1 MB user data memory with recipe management capability supports up to 500 recipe lines per recipe, enabling setpoint parameter storage for production changeovers in packaging and food processing machinery without PC connectivity.
التطبيقات الصناعية
- Water pump station and pressure boosting system operator interfaces for residential compounds and commercial buildings across Riyadh, Jeddah, and the Eastern Province, providing Arabic-language status display and setpoint adjustment for site operators.
- HVAC air handling unit local control panels in commercial towers and government buildings, where the KTP900 Basic's BACnet-proxy communication via the connected PLC allows BMS integration without replacing the HMI.
- Packaging machine operator stations in Saudi food and pharmaceutical manufacturing facilities, where the recipe management function stores up to 500 product changeover setpoints for quick format changeovers.
- Conveyor system local operator panels in logistics and warehousing facilities, where operators use the function keys for start, stop, jog, and speed preset commands while wearing heavy industrial gloves.
- Water treatment plant chemical dosing and filtration control panels at municipal water facilities operated by NWC, where Arabic-language alarm messages are mandatory for compliance with Saudi operator qualification requirements.
- Diesel generator and UPS control panels at critical facilities including hospitals and data centres, where the KTP900 Basic displays generator status, load percentage, and fuel level with local alarm acknowledgement.
- MODON industrial estate machinery OEM export panels destined for GCC and MENA markets, where the CE marking and Siemens global service network provide the end-user confidence required for export machinery sales.
مورد معتمد في المملكة العربية السعودية
احصل على عرض سعر لـ لوحة HMI الأساسية SIMATIC KTP900 من سيمنز
نرد خلال 4 ساعات. أرسل رقم الموديل 6AV2123-2JB03-0AX0 للحصول على سعر تنافسي مع التسليم في أنحاء المملكة العربية السعودية والخليج.
أسئلة شائعة حول لوحة HMI الأساسية SIMATIC KTP900 من سيمنز
أكثر الأسئلة شيوعاً من العملاء في المملكة العربية السعودية
