مقياس التدفق الكهرومغناطيسي SITRANS FM MAG 5100W من سيمنز
رقم الموديل: 7ME6520-2CA13-1AA1
Pipe Sizes: DN15–DN1200Lining: PTFE, hard rubber, PFAElectrodes: Hastelloy C, stainless steel, platinumOutput: 4–20 mA HART 7 + pulse output
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
مقياس التدفق الكهرومغناطيسي SITRANS FM MAG 5100W من سيمنز — نظرة عامة
مقياس التدفق الكهرومغناطيسي SITRANS FM MAG 5100W من سيمنز لقياس تدفق السوائل الموصلة من DN15 إلى DN1200. لا توجد أجزاء متحركة ولا سقوط ضغط مع مبطنات PTFE ومطاط قاسٍ وأقطاب Hastelloy C. يعمل مع جهاز إرسال MAG 6000 بمخرج 4-20mA وHART 7.
يُستخدم في محطات تحلية SWCC وMARAFIQ وشبكات مياه NWC ومرافق مياه SABIC في الجبيل. توفر راز الشرق الأوسط هذه الأجهزة بجميع الأقطار مع شهادات معايرة المصنع وخدمات التحقق في الموقع.
المواصفات الفنية
المواصفات الكاملة لـ 7ME6520-2CA13-1AA1
- Pipe Sizes
- DN15–DN1200
- Lining
- PTFE, hard rubber, PFA
- Electrodes
- Hastelloy C, stainless steel, platinum
- Output
- 4–20 mA HART 7 + pulse output
- Accuracy
- 0.4% of flow rate
- Process Pressure
- Up to 40 bar (DN15–DN200)
- Process Temp
- -20 to +60°C (hard rubber); up to +130°C (PTFE)
- Certification
- ATEX Zone 1 / IECEx Ex d (optional)
- Flow Direction
- Bidirectional
- Compliance
- IEC 60529 (IP67), OIML R49 (water)
المميزات والفوائد
- No moving parts and zero pressure drop delivers the lowest lifecycle maintenance cost for clean liquid flow measurement, eliminating the impeller wear and bearing replacement costs of mechanical meter technologies.
- Bidirectional flow measurement with the same accuracy in both forward and reverse directions enables pipeline leak detection by comparing flow at both ends of a distribution pipeline segment.
- OIML R49 water meter approval allows the MAG 5100W to be used for billing-grade water measurement between utilities and industrial users, satisfying the Saudi legal metrology requirements for custody transfer metering.
- PTFE lining provides chemical inertness to highly aggressive liquids including concentrated acids, alkalis, and hypochlorite — the primary disinfectant used at Saudi water treatment facilities — without lining degradation.
- Hastelloy C electrodes resist the mildly corrosive seawater and brine media at SWCC and MARAFIQ desalination plants, where stainless steel electrodes would suffer chloride pitting in the high-salinity feed water.
- HART 7 communication provides device diagnostics including electrode coating detection, empty pipe detection, and process noise alerts, enabling proactive maintenance scheduling before measurement accuracy degrades.
- Large-diameter availability from DN600 to DN1200 provides the bore sizes required for the main transmission mains at water treatment and desalination transfer pumping stations where volumes of billions of litres per day are metered.
التطبيقات الصناعية
- Treated seawater production metering at SWCC and MARAFIQ reverse osmosis desalination plants, where DN600 to DN1200 MAG 5100W meters on plant output headers provide the production accounting volumes for inter-authority water tariff billing.
- Municipal water distribution network flow measurement at NWC district metering areas (DMAs) across Saudi cities, where bidirectional flow meters at DMA boundaries enable network hydraulic modelling and non-revenue water loss detection.
- SABIC industrial utility cooling water flow metering at Jubail petrochemical complex, where the meter's no-maintenance design reduces instrument maintenance workload at facilities with thousands of measurement points.
- Wastewater and effluent flow measurement at industrial wastewater treatment plants in MODON industrial estates, where hard rubber lining handles the abrasive suspended solids in raw wastewater influent streams.
- Irrigation water distribution metering at large-scale agricultural and landscaping projects under Saudi Vision 2030, where accurate volumetric measurement supports water efficiency KPIs and conservation reporting.
- Chemical dosing flow verification at water treatment chlorination and coagulant dosing stations, where small-diameter DN15–DN25 MAG meters provide accurate verification of chemical injection rates for process control.
- Produced water and injection water metering at Aramco water injection facilities, where the bidirectional flow capability allows the same meter to measure injection flow and flowback from the reservoir under different operating conditions.
مورد معتمد في المملكة العربية السعودية
احصل على عرض سعر لـ مقياس التدفق الكهرومغناطيسي SITRANS FM MAG 5100W من سيمنز
نرد خلال 4 ساعات. أرسل رقم الموديل 7ME6520-2CA13-1AA1 للحصول على سعر تنافسي مع التسليم في أنحاء المملكة العربية السعودية والخليج.
