لوحة HMI SIMATIC TP700 Comfort من سيمنز
رقم الموديل: 6AV2124-0GC01-0AX0
Display: 7" widescreen TFT, 800×480 pixelsBrightness: 450 nitsFront Panel: IP65 ratedUser Memory: 12 MB application
متوفر — يُشحن داخل المملكة العربية السعودية
نرد خلال 4 ساعات عمل · الأسعار بالريال السعودي · توصيل لجميع مدن المملكة
منتجات أصلية 100%
رد خلال 4 ساعات
توصيل لجميع أنحاء المملكة
دعم فني متكامل
لوحة HMI SIMATIC TP700 Comfort من سيمنز — نظرة عامة
لوحة SIMATIC TP700 Comfort من سيمنز هي لوحة HMI بشاشة لمس 7 بوصة عريضة بدقة 800×480 وحماية IP65 مع دعم اللغة العربية وبرمجة TIA Portal WinCC Comfort.
المعيار القياسي في لوحات الأتمتة الصناعية في المملكة العربية السعودية لدى ARAMCO وSABIC وNWC. توفر راز الشرق الأوسط TP700 مع تطوير واجهة HMI كاملة بالعربي والإنجليزي.
المواصفات الفنية
المواصفات الكاملة لـ 6AV2124-0GC01-0AX0
- Display
- 7" widescreen TFT, 800×480 pixels
- Brightness
- 450 nits
- Front Panel
- IP65 rated
- User Memory
- 12 MB application
- Communication
- PROFINET (1 port), MPI/PROFIBUS, USB 2.0
- Touch
- Multi-touch (2-point)
- Operating Temp
- 0 to +50°C
- Software
- TIA Portal WinCC Comfort
- Language Support
- 32 languages including Arabic
المميزات والفوائد
- TIA Portal WinCC Comfort configuration within the same engineering environment as S7-1200/S7-1500 PLC programming eliminates separate HMI tools, reducing total automation project engineering time by up to 30% versus multi-tool approaches.
- IP65 front panel sealing against dust and water jets enables panel-door mounting in production environments, food processing facilities, and outdoor plant enclosures where spray cleaning and airborne particles are present.
- Arabic language support with right-to-left text rendering and Arabic character input delivers full Arabic operator interface capability — alarm messages, process descriptors, and operator instructions — satisfying Saudi workplace language requirements.
- Multi-touch operation with pinch-to-zoom and two-finger gesture navigation provides a natural interaction model that reduces operator training time on complex process graphics with multiple zoom levels.
- 12 MB user application memory supports complex HMI projects with hundreds of screens, extensive alarm databases, multi-parameter trend archives, and recipe management systems required in sophisticated industrial visualisation applications.
- PDF and HTML viewer built into the Comfort Panel runtime allows display of machine manuals, maintenance procedures, and P&ID drawings directly on the HMI panel, providing operators with document access at the point of need.
- Integrated recipe management with import/export capability enables product changeover parameter loading from a USB drive or PROFINET network share, reducing changeover time in batch process and multi-product manufacturing applications.
التطبيقات الصناعية
- Water treatment plant operator interfaces at NWC municipal pumping stations and private water treatment facilities, where Arabic-language screen support ensures local operators can monitor process parameters and acknowledge alarms in their working language.
- HVAC plant room operator panels in commercial towers and hospitals across Riyadh and Jeddah, where the TP700's IP65 sealing withstands the humidity and cleaning typical of plant rooms while displaying AHU and chiller status screens.
- Industrial machine tool control panel HMI for Saudi precision manufacturing facilities, where the TP700's multi-touch interface provides intuitive axis position display, program selection, and machine status monitoring.
- Petrochemical process skid HMI displays for packaged pump, compressor, and heat exchanger skids supplied to ARAMCO and SABIC facilities, where TIA Portal S7-1200+TP700 packages provide a complete self-contained skid automation solution.
- Desalination pre-treatment process operator stations at SWCC and private RO desalination plants, where the TP700 displays membrane pressure, flow rates, and system alarms with Arabic-language operator instructions.
- Building automation integration panels for NEOM and Vision 2030 infrastructure projects, where the TP700's OPC UA communication capability provides standardised data exchange with SCADA systems and building management platforms.
- Cement plant process control panels at Saudi Cement and Yamama Cement facilities, where TP700 panels display kiln temperatures, material flow rates, and quality control parameters with trend curves showing production history.
