LS Electric SV iS7 Advanced Inverter

The LS Electric SV iS7 Advanced Inverter is LS Electric's flagship industrial drive platform, combining best-in-class vector control performance with an extensive application feature set designed to satisfy the most demanding automation engineers in Saudi Arabia's process industries. The iS7 covers 0.75 kW to 630 kW on 380–480 V three-phase, with a 690 V option available for high-voltage industrial installations. The drive offers true closed-loop vector control with encoder feedback (iV5-class speed accuracy) alongside enhanced sensorless vector operation for applications where encoder cabling is impractical. The iS7's most distinctive feature is its embedded high-capacity PLC — 10,000 steps of IEC 61131-3 compliant ladder, function block, and structured text programming — effectively making the drive a standalone micro-automation controller capable of executing complete machine sequences without an external PLC in many applications.

The iS7's fieldbus architecture is the most comprehensive in the LS Electric range, with built-in RS-485 Modbus RTU and an expansion bus accepting dual simultaneous optional protocol cards — allowing a single drive to communicate with a PLC via EtherNet/IP and a SCADA system via PROFIBUS-DP simultaneously. Built-in safety conforms to SIL 2 / PLd, covering STO, SS1, SS2, and SLS functions, meeting the machine safety requirements of IEC 62061 and EN ISO 13849-1 without external safety relays. The drive's hardware design includes a built-in harmonic mitigation inductor (DC reactor) on frames from 22 kW upwards, reducing supply-side harmonic distortion to below IEC 61000-3-12 limits — important for compliance in Saudi Arabia's SEC grid-connected industrial facilities.

Engineering contractors working on major Saudi Arabia infrastructure projects — including NEOM transport and utility systems, SABIC and Saudi Aramco process plant upgrades, and MODON industrial city expansions — are increasingly specifying the iS7 in place of higher-priced European alternatives at equivalent technical ratings. The iS7's SIL 2 safety, dual-protocol communications, and IEC 61131-3 PLC capability match European drive feature sets point-for-point, while Razz Middle East's local stocking and engineering support provides the supply chain confidence that project contractors require. The drive operates to 50°C ambient as standard, with an optional liquid-cooled variant available for especially high-ambient or high-density drive cabinet installations.

Razz Middle East maintains stock of the iS7 in power ratings from 0.75 kW to 132 kW in our Saudi Arabia warehouse, with 160 kW to 630 kW frames available within 4–6 weeks. We provide turnkey services including drive selection, panel design review, commissioning, PLC function programming, and operator training. A 12-month warranty is standard with 24-month extended warranty available on stocking orders.
