LS Electric
LS Electric BKN Miniature Circuit Breaker
Model: BKN-B16-1P
4-hour response · Pricing in SAR · Delivery across all KSA regions
LS Electric BKN Miniature Circuit Breaker
The LS Electric BKN Miniature Circuit Breaker is a compact, IEC 60898-compliant overcurrent protective device designed for the protection of final distribution circuits in residential, commercial, and light industrial electrical installations across Saudi Arabia. Available in 1-pole, 2-pole, 3-pole, and 4-pole configurations from 6 A to 63 A, with trip characteristic curves B, C, and D (to IEC 60947-2 industrial versions), the BKN covers the full range of final circuit applications from lighting and socket outlet circuits in residential buildings to motor branch circuits and distribution feeder protection in industrial distribution boards. The BKN's compact 17.8 mm per pole pitch matches the standard DIN EN 60715 rail spacing used in Saudi Arabia's panel building industry, making it dimensionally compatible with existing panel layouts when replacing other branded MCBs.
The BKN's breaking capacity is 6 kA at 230/400 V AC (standard BKN) — sufficient for most residential and commercial distribution board applications in Saudi Arabia where the prospective short-circuit current at the point of installation is within this range. The BKN-H variant with 10 kA breaking capacity is available for higher fault-level locations such as main distribution boards and industrial panel incomer protection. The BKN's double-break contact geometry provides reliable interruption of fault current and a long contact life under repeated over-current clearing operations. An LED trip indicator on the BKN-H variant provides visual confirmation of trip versus manual-off status, simplifying fault finding during maintenance.
LS Electric BKN circuit breakers are among the most cost-effective MCB options available in the Saudi Arabia electrical market, typically priced 20–35% below equivalent Siemens 5SL and ABB S200 MCBs at the same ampere rating and breaking capacity. This price advantage, combined with full IEC 60898 and IEC 60947-2 compliance, makes them the preferred choice for Saudi electrical contractors, panel builders, and project developers seeking to reduce material costs on large projects where MCB quantities run into the thousands of units — such as residential compounds, NEOM worker accommodation, MODON factory buildings, and commercial tower developments.
Razz Middle East supplies the BKN range in all standard pole configurations, current ratings, and trip curves for immediate supply in Saudi Arabia. We offer volume pricing for electrical contractors and panel builders, and our team provides product selection guidance for circuit protection sizing to Saudi Electrical Code (SEC) distribution board standards.
Technical Specifications
Full specifications for the BKN-B16-1P
- Current Range
- 6–63 A
- Pole Configurations
- 1P, 2P, 3P, 4P
- Trip Curves
- B, C, D
- Breaking Capacity
- 6 kA (BKN) / 10 kA (BKN-H)
- Pitch
- 17.8 mm per pole
- Standard
- IEC 60898 / IEC 60947-2
- Mounting
- 35 mm DIN rail
- Voltage
- 230/400 V AC
Key Features & Benefits
- Full IEC 60898 compliance at 17.8 mm/pole DIN pitch — dimensionally compatible with all standard panel layouts.
- BKN-H 10 kA variant available for main distribution board and higher fault-level protection applications.
- Trip curves B, C, D available to match circuit load characteristics from lighting to motor branch circuits.
- 20–35% lower SAR cost versus Siemens 5SL and ABB S200 equivalents at same IEC rating.
- Double-break contact geometry ensures reliable fault current interruption and extended contact life.
Industrial Applications in Saudi Arabia
- Final circuit protection in residential distribution boards across Saudi Arabia housing and compound projects.
- Commercial building distribution panels in office towers, hotels, and retail developments.
- Industrial panel board branch circuit protection in factories and infrastructure facilities.
- NEOM and Vision 2030 large-scale residential and commercial development electrical installations.
- Retrofit MCB replacement in existing panel boards at Saudi industrial and commercial facilities.
Industrial Supplier in Saudi Arabia
Get a Quote for the LS Electric BKN Miniature Circuit Breaker
We respond within 4 business hours. Send model BKN-B16-1P for competitive pricing in SAR with delivery across Saudi Arabia and the GCC.
Frequently Asked Questions — BKN-B16-1P
Common questions from buyers in Saudi Arabia and the GCC
What is the LS Electric BKN Miniature Circuit Breaker (BKN-B16-1P) and what is it used for?
The LS Electric BKN Miniature Circuit Breaker is a compact, IEC 60898-compliant overcurrent protective device designed for the protection of final distribution circuits in residential, commercial, and light industrial electrical installations across Saudi Arabia. Available in 1-pole, 2-pole, 3-pole, and 4-pole configurations from 6 A to 63 A, with trip characteristic curves B, C, and D (to IEC 60947-2 industrial versions), the BKN covers the full range of final circuit applications from lighting and socket outlet circuits in residential buildings to motor branch circuits and distribution feeder protection in industrial distribution boards. The BKN's compact 17.8 mm per pole pitch matches the standard DIN EN 60715 rail spacing used in Saudi Arabia's panel building industry, making it dimensionally compatible with existing panel layouts when replacing other branded MCBs.
Where can I buy the LS Electric BKN-B16-1P in Saudi Arabia?
Razz Middle East supplies genuine LS Electric products including the LS Electric BKN Miniature Circuit Breaker (BKN-B16-1P) across all regions of Saudi Arabia — Riyadh, Jeddah, Dammam, Al Khobar, Jubail, Yanbu, Mecca, and Medina. We source fast-moving items to order and can source specialist configurations. Request a quote on this page for same-day pricing.
How do I get the best price for the BKN-B16-1P in KSA?
Click "Request Free Quote" on this page or message us the model number BKN-B16-1P on WhatsApp. Our technical sales team responds within 4 business hours with a competitive price in SAR and a confirmed delivery lead time — with no hidden charges or handling fees.
Does Razz Middle East supply genuine LS Electric products in Saudi Arabia?
Yes. Razz Middle East is an independent industrial supplier, not an appointed LS Electric distributor. We source through LS Electric OEM channels or through authorised LS Electric distributor channels and supply 100% genuine product with full manufacturer warranty and documentation, serving the oil & gas, petrochemical, power generation, water, construction and manufacturing sectors across the Kingdom.
What is the delivery lead time for the LS Electric BKN Miniature Circuit Breaker in Saudi Arabia?
Items are sourced to order and delivered duty-paid, typically 2-3 weeks, to Riyadh, Dammam, Jeddah and the Eastern Province. Project orders and non-standard configurations can take longer. Contact us with the exact model number BKN-B16-1P to confirm the lead time for your quantity.
Can the BKN-B16-1P be supplied for industrial projects in KSA?
Yes. Razz Middle East is an approved vendor to SABIC, Ma'aden, Sadara, Saudi Energy, ACWA Power, Safari Group and others. For project orders we provide the manufacturer's technical documentation and certificates of conformity for your vendor approval file. Contact our project team with your project specification.
