Schneider Electric Altivar 600 General Purpose Drive
Model: ATV600C11N4
4-hour response · Pricing in SAR · Delivery across all KSA regions
Schneider Electric Altivar 600 General Purpose Drive
The Schneider Electric Altivar 600 is a general-purpose variable speed drive covering 0.75 kW to 630 kW on 380–480 V three-phase supply, designed to deliver industrial-grade reliability with a comprehensive standard feature set that eliminates the need for most optional add-on modules. The ATV600 ships standard with an IP55 enclosure option on frames up to 90 kW, built-in EMC filter, and embedded EcoStruxure connectivity for IIoT monitoring and predictive maintenance — features that competing drives typically charge extra for. Its intuitive graphical keypad with embedded QR code service access reduces commissioning effort and enables quick access to Schneider Electric's online drive documentation and support resources without carrying printed manuals on site.
The ATV600 delivers both scalar and sensorless vector control, with closed-loop flux vector available via encoder card for demanding speed and torque regulation applications. The motor control algorithm supports asynchronous induction motors as well as synchronous reluctance motors (SyRM) and permanent magnet motors, enabling seamless adoption of Schneider Electric's IE4-class SyRM motor and drive packages that deliver up to 10% better system efficiency compared to standard IE3 motor and drive combinations. Built-in load sharing and master/follower functions simplify multi-drive installations for long conveyor systems, crane hoists, and multi-pump configurations.
Across Saudi Arabia, the Altivar 600 KSA addresses the broad mid-range industrial market from light process equipment to demanding continuous-duty applications. Saudi Aramco operations and maintenance contractors specify the ATV600 for utility pump and fan drives where IP55 protection enables direct installation without additional enclosures. Ma'aden mining operations at Al Khali and Wa'ad Al-Shamal use ATV600-driven conveyors and crushers for mineral processing. The drive's EcoStruxure connectivity aligns with Saudi Arabia's industrial digitalisation agenda under Vision 2030, providing live drive data to cloud-based maintenance platforms.
Razz Middle East stocks ATV600 drives from 0.75 kW to 250 kW in IP21 and IP55 variants for same-week delivery. Our engineers provide full commissioning, EcoStruxure cloud setup, and preventive maintenance programmes across all major Saudi industrial cities.
Technical Specifications
Full specifications for the ATV600C11N4
- Voltage Range
- 380–480 V AC three-phase
- Power Range
- 0.75–630 kW
- Control
- Scalar / Sensorless vector / Flux vector
- Enclosure
- IP21 / IP55
- Communication
- Modbus TCP + EtherNet/IP built-in
- Motor Types
- Asynchronous, SyRM, PM
- EcoStruxure
- Built-in IIoT connectivity
- Ambient Temperature
- -15 to +50°C
- Load Sharing
- Built-in master/follower
- EMC Filter
- Built-in
Key Features & Benefits
- IP55 enclosure option on frames up to 90 kW ships as standard (no add-on kit required), enabling direct outdoor or dusty environment installation without an additional weatherproof enclosure cabinet.
- EcoStruxure IIoT connectivity built-in provides live drive health data — load, temperature, run hours, fault history — to Schneider Electric's cloud monitoring platform for predictive maintenance scheduling.
- Synchronous reluctance motor (SyRM) support enables up to 10% better system efficiency versus standard IE3 motor and drive packages when paired with Schneider Electric's IE4 SyRM motor range.
- Built-in Modbus TCP and EtherNet/IP communication ports allow simultaneous SCADA connection and EcoStruxure cloud data upload without additional communication cards or port conflicts.
- Master/follower load sharing function synchronises multiple ATV600 drives on shared mechanical loads such as long conveyors and overhead crane hoists without external synchronisation controllers.
- Embedded QR code on the drive keypad links to online documentation, parameter lists, and service resources, enabling field technicians to access current information without printed manuals.
- Auto-tuning routine for SyRM and PM motors characterises motor parameters in under two minutes during commissioning, optimising vector control performance without manual calculation.
Industrial Applications in Saudi Arabia
- Utility pump and fan drives at Saudi Aramco production facilities in the Eastern Province, where IP55 protection allows direct installation in outdoor utility areas without additional weatherproof cabinets.
- Mineral conveyor and crusher drives at Ma'aden phosphate and gold mining operations in northern Saudi Arabia, where master/follower load sharing maintains tension balance across multi-drive long conveyors.
- HVAC chilled water pump and AHU fan drives in large commercial and industrial buildings across Riyadh, Jeddah, and Dammam, where EcoStruxure connectivity enables energy performance reporting for LEED certification.
- Water injection and transfer pump drives in SABIC petrochemical process plants at Jubail, where IP55 protection and robust sensorless vector control provide reliable 24/7 operation in outdoor pump stations.
- Desalination pre-treatment pump drives at SWCC and NWC water infrastructure projects, where the drive's broad power range allows standardisation on a single product family from small dosing pumps to large transfer pumps.
- Compressor auxiliary and cooling fan drives at SEC power generation facilities, where EcoStruxure monitoring provides advance warning of drive thermal degradation in high-ambient plant rooms.
- Cement plant raw mill, kiln drive, and cooler fan applications at Saudi cement manufacturers in Riyadh and Jizan regions, where high ambient temperature tolerance and dustproof IP55 construction are mandatory requirements.
Industrial Supplier in Saudi Arabia
Get a Quote for the Schneider Electric Altivar 600 General Purpose Drive
We respond within 4 business hours. Send model ATV600C11N4 for competitive pricing in SAR with delivery across Saudi Arabia and the GCC.
Frequently Asked Questions — ATV600C11N4
Common questions from buyers in Saudi Arabia and the GCC
What is the Schneider Electric Altivar 600 General Purpose Drive (ATV600C11N4) and what is it used for?
The Schneider Electric Altivar 600 is a general-purpose variable speed drive covering 0.75 kW to 630 kW on 380–480 V three-phase supply, designed to deliver industrial-grade reliability with a comprehensive standard feature set that eliminates the need for most optional add-on modules. The ATV600 ships standard with an IP55 enclosure option on frames up to 90 kW, built-in EMC filter, and embedded EcoStruxure connectivity for IIoT monitoring and predictive maintenance — features that competing drives typically charge extra for. Its intuitive graphical keypad with embedded QR code service access reduces commissioning effort and enables quick access to Schneider Electric's online drive documentation and support resources without carrying printed manuals on site.
Where can I buy the Schneider Electric ATV600C11N4 in Saudi Arabia?
Razz Middle East supplies genuine Schneider Electric products including the Schneider Electric Altivar 600 General Purpose Drive (ATV600C11N4) across all regions of Saudi Arabia — Riyadh, Jeddah, Dammam, Al Khobar, Jubail, Yanbu, Mecca, and Medina. We maintain local stock on fast-moving items and can source specialist configurations. Request a quote on this page for same-day pricing.
How do I get the best price for the ATV600C11N4 in KSA?
Click "Request Free Quote" on this page or message us the model number ATV600C11N4 on WhatsApp. Our technical sales team responds within 4 business hours with a competitive price in SAR, confirmed stock availability, and delivery lead time — with no hidden charges or handling fees.
Is Razz Middle East an authorized Schneider Electric supplier in Saudi Arabia?
Razz Middle East is a specialist industrial equipment supplier in Saudi Arabia focused on Schneider Electric and other leading global brands. We supply 100% genuine OEM products backed by full manufacturer warranty, serving the oil & gas, petrochemical, power generation, water, construction, and manufacturing sectors across the Kingdom.
What is the delivery lead time for the Schneider Electric Altivar 600 General Purpose Drive in Saudi Arabia?
In-stock items typically ship within 24-48 hours to Riyadh, Dammam, Jeddah, and the Eastern Province. Project orders and non-standard configurations generally take 2-6 weeks. Contact us with the exact model number ATV600C11N4 for a precise availability confirmation and delivery date.
Can the ATV600C11N4 be supplied for ARAMCO, SABIC, or NEOM projects in KSA?
Yes. Razz Middle East has experience supplying Schneider Electric equipment to major industrial projects and EPC contractors across Saudi Arabia. We can provide full technical documentation, Material Inspection Reports (MIR), and certificates of conformity to meet vendor approval requirements. Contact our project team to discuss your specific project requirements.
