Schneider Electric PrismaSeT P Low Voltage Switchboard
Model: LVS08501
4-hour response · Pricing in SAR · Delivery across all KSA regions
Schneider Electric PrismaSeT P Low Voltage Switchboard
The Schneider Electric PrismaSeT P is a fully type-tested, IEC 61439-2 compliant low-voltage switchboard system covering 63 A to 4000 A for main and sub-main power distribution in commercial buildings, industrial facilities, and infrastructure projects. The PrismaSeT P is a functional unit switchboard — each circuit breaker, switch, fuse, or metering device occupies a standardised functional unit (FU) column within the switchboard framework — providing a structured, accessible, and extensible distribution assembly that can be delivered partially loaded and field-extended at a later date without structural modification to the switchboard enclosure.
The PrismaSeT P enclosure is manufactured from zinc-coated steel with IP30 to IP55 protection options, rated for operation at 50°C ambient temperature as tested under IEC 61439-2 — directly addressing Saudi Arabia's electrical room temperature conditions without additional air conditioning. The system accommodates the full Schneider Electric circuit protection range from Acti9 iC60 MCBs to ComPacT NSX MCCBs to MasterPact MTZ ACBs, with pre-engineered functional unit forms covering fixed, plug-in, and draw-out circuit breaker mounting variants. The PrismaSeT P is available as a floor-standing assembly in standard IP31/IP43/IP54 enclosure ratings or as a wall-mounted version for smaller distribution requirements.
In Saudi Arabia, the PrismaSeT P KSA is used by Schneider Electric's network of approved LV switchboard manufacturers in Riyadh, Jeddah, and Dammam to build IEC 61439-2 type-tested switchboards for commercial, industrial, and infrastructure projects. ARAMCO-approved LV switchboard suppliers use PrismaSeT P for motor control centre and process plant distribution board projects. SEC-approved panel builders use PrismaSeT P for utility substation LV distribution. Government building project consultants specify PrismaSeT P as the distribution switchboard standard for Ministry of Finance and Ministry of Education capital programmes.
Razz Middle East works with PrismaSeT P switchboard panel builders across Saudi Arabia to supply the Schneider Electric switchboard components — circuit breakers, busbars, functional units, enclosures, and metering — with full IEC 61439-2 test documentation and project coordination support.
Technical Specifications
Full specifications for the LVS08501
- Current Range
- 63–4000 A
- Standard
- IEC 61439-2 type-tested
- Ambient Temperature
- 50°C (tested)
- Enclosure
- IP30/IP43/IP54/IP55
- Circuit Breakers
- Acti9, NSX, MasterPact (all compatible)
- Functional Units
- Fixed / Plug-in / Draw-out
- Mounting
- Floor-standing or wall-mounted
- Busbar System
- Horizontal + vertical copper busbars
Key Features & Benefits
- IEC 61439-2 type-tested performance data at 50°C ambient covers Saudi Arabia's electrical room conditions, providing certified switchboard performance without additional air conditioning in standard plant room installations.
- Functional unit switchboard architecture allows future circuit additions without structural modification, protecting the original switchboard investment when additional circuits are required during building expansion or process changes.
- Compatibility with Acti9, ComPacT NSX, and MasterPact MTZ circuit breakers in a single enclosure enables a complete Schneider Electric protection hierarchy from final circuit MCBs to main distribution ACBs in one coordinated system.
- Draw-out functional unit versions allow circuit breaker maintenance and replacement without de-energising the adjacent busbar, maintaining distribution continuity during planned maintenance shutdowns.
- IP54 enclosure option provides protection against dust and water splash in industrial environments such as process plant electrical rooms, outdoor kiosks, and factory floor distribution boards.
- Pre-engineered functional unit forms with Schneider Electric circuit breaker dimensions reduce switchboard manufacturer engineering time and eliminate field measurement errors during panel assembly.
- EcoStruxure Power compatibility via Micrologic trip units in installed circuit breakers provides live energy management data to building or plant management systems from the switchboard's circuit breaker population.
Industrial Applications in Saudi Arabia
- ARAMCO-approved panel builder LV motor control centres and process plant distribution switchboards at Eastern Province and Jubail facilities, where IEC 61439-2 certification satisfies ARAMCO electrical engineering standard requirements.
- Commercial tower main LV distribution switchboard assemblies in Riyadh KAFD and Jeddah downtown, where PrismaSeT P's functional unit architecture enables circuit additions without reconstruction during tenant fit-out.
- SEC-approved utility substation LV distribution panel assemblies for 11 kV/400 V step-down stations, where IEC 61439-2 type testing satisfies SEC's LV switchgear approval requirements.
- Ministry of Health hospital main distribution switchboard assemblies in new facility construction, where draw-out circuit breaker capability enables maintenance without supply interruption to critical patient care circuits.
- ROSHN community centre and large commercial building main distribution switchboards, where EcoStruxure Power metering capability provides building energy consumption monitoring to the community management platform.
- Industrial facility motor control centres at MODON industrial city large-scale manufacturers, where PrismaSeT P functional unit form covers MCC feeder and outgoing motor starter circuit breaker mounting.
- Data centre main and UPS output distribution switchboards at Riyadh and Jeddah hyperscale facilities, where draw-out architecture and 50°C ambient rating satisfy both operational and temperature management requirements.
Industrial Supplier in Saudi Arabia
Get a Quote for the Schneider Electric PrismaSeT P Low Voltage Switchboard
We respond within 4 business hours. Send model LVS08501 for competitive pricing in SAR with delivery across Saudi Arabia and the GCC.
Frequently Asked Questions — LVS08501
Common questions from buyers in Saudi Arabia and the GCC
What is the Schneider Electric PrismaSeT P Low Voltage Switchboard (LVS08501) and what is it used for?
The Schneider Electric PrismaSeT P is a fully type-tested, IEC 61439-2 compliant low-voltage switchboard system covering 63 A to 4000 A for main and sub-main power distribution in commercial buildings, industrial facilities, and infrastructure projects. The PrismaSeT P is a functional unit switchboard — each circuit breaker, switch, fuse, or metering device occupies a standardised functional unit (FU) column within the switchboard framework — providing a structured, accessible, and extensible distribution assembly that can be delivered partially loaded and field-extended at a later date without structural modification to the switchboard enclosure.
Where can I buy the Schneider Electric LVS08501 in Saudi Arabia?
Razz Middle East supplies genuine Schneider Electric products including the Schneider Electric PrismaSeT P Low Voltage Switchboard (LVS08501) across all regions of Saudi Arabia — Riyadh, Jeddah, Dammam, Al Khobar, Jubail, Yanbu, Mecca, and Medina. We maintain local stock on fast-moving items and can source specialist configurations. Request a quote on this page for same-day pricing.
How do I get the best price for the LVS08501 in KSA?
Click "Request Free Quote" on this page or message us the model number LVS08501 on WhatsApp. Our technical sales team responds within 4 business hours with a competitive price in SAR, confirmed stock availability, and delivery lead time — with no hidden charges or handling fees.
Is Razz Middle East an authorized Schneider Electric supplier in Saudi Arabia?
Razz Middle East is a specialist industrial equipment supplier in Saudi Arabia focused on Schneider Electric and other leading global brands. We supply 100% genuine OEM products backed by full manufacturer warranty, serving the oil & gas, petrochemical, power generation, water, construction, and manufacturing sectors across the Kingdom.
What is the delivery lead time for the Schneider Electric PrismaSeT P Low Voltage Switchboard in Saudi Arabia?
In-stock items typically ship within 24-48 hours to Riyadh, Dammam, Jeddah, and the Eastern Province. Project orders and non-standard configurations generally take 2-6 weeks. Contact us with the exact model number LVS08501 for a precise availability confirmation and delivery date.
Can the LVS08501 be supplied for ARAMCO, SABIC, or NEOM projects in KSA?
Yes. Razz Middle East has experience supplying Schneider Electric equipment to major industrial projects and EPC contractors across Saudi Arabia. We can provide full technical documentation, Material Inspection Reports (MIR), and certificates of conformity to meet vendor approval requirements. Contact our project team to discuss your specific project requirements.
