Schneider Electric TeSys K Mini Contactor
Model: LC1K0610M7
4-hour response · Pricing in SAR · Delivery across all KSA regions
Schneider Electric TeSys K Mini Contactor
The Schneider Electric TeSys K is a miniature contactor covering 6 A to 25 A for small three-phase and single-phase motor and load switching applications on supply voltages up to 690 V AC, offering a compact and cost-effective solution for multi-motor machine control cabinets, small DOL starters, and auxiliary load switching where the TeSys D series would over-specify and over-price the application. The LC1K series occupies only 32 mm DIN rail width in the smallest frame — significantly narrower than the 45 mm minimum of TeSys D — enabling higher motor circuit density in space-constrained machine panels and providing a meaningful cost reduction per axis in multi-drive machine applications.
Despite its miniature size, the TeSys K delivers full IEC 60947-4-1 compliance with AC-3 motor switching utilisation category, coil voltages ranging from 24 V to 480 V AC and 24 V to 220 V DC, and a built-in 1 NO auxiliary contact. The add-on auxiliary contact blocks, timer modules, and suppression modules from the TeSys K accessory range are compatible with the same tool-free snap-fit system as TeSys D, enabling complex control logic with a compact footprint. The TeSys K is particularly suited to applications where space is the primary constraint — door-mounted panels, machine junction boxes, and compact MCC feeder sections — and where motor powers below 11 kW at 400 V represent the entire motor population.
In Saudi Arabia, the TeSys K mini contactor serves the OEM machinery, building services, and light commercial sectors where the TeSys D's larger format is unnecessary. Saudi OEMs building multi-conveyor sorting systems, material handling equipment, and packaging lines use TeSys K for individual motor switching axes where panel space is the binding constraint. Building services panels for fan coil units in hotels and commercial buildings use TeSys K for individual room fan motor switching where dozens of contactors must fit in a compact distribution board.
Razz Middle East stocks TeSys K mini contactors in 6 A and 9 A ratings with the most common coil voltages (24 V AC, 110 V AC, 230 V AC, 24 V DC) for immediate delivery.
Technical Specifications
Full specifications for the LC1K0610M7
- Current Range
- 6–25 A (LC1K series)
- Voltage
- Up to 690 V AC
- Utilization
- AC-3
- DIN Rail Width
- 32 mm (smallest frame)
- AC Coil Voltages
- 24–480 V AC
- DC Coil Voltages
- 24–220 V DC
- Built-in Aux
- 1 NO
- Motor Power (400V)
- Up to 11 kW
- Standard
- IEC 60947-4-1
Key Features & Benefits
- 32 mm DIN rail width in the smallest frame is significantly narrower than TeSys D, enabling higher motor contactor density per metre of DIN rail in compact machine panels and multi-motor control cabinets.
- Lower unit cost versus TeSys D for the same current rating provides meaningful per-axis savings in multi-motor machine applications where dozens of small motor contactors are required per machine.
- Full IEC 60947-4-1 AC-3 compliance in a miniature body delivers the same utilisation category performance and endurance ratings as the TeSys D family for motor powers up to 11 kW at 400 V.
- Tool-free snap-fit auxiliary contact blocks and timer modules from the TeSys K accessory range are compatible with the same assembly technique as TeSys D, reducing panel assembly time across the full contactor range.
- Wide coil voltage range (24 V to 480 V AC, 24 V to 220 V DC) matches all standard control circuit voltages in Saudi Arabia's OEM machinery, building services, and commercial installation markets.
- Compact depth of 68 mm allows front-panel mounting in shallow machine junction boxes and door panels where standard TeSys D depth (86 mm minimum) would not fit behind panel cutouts.
- Direct combination with TeSys GV2 motor protection circuit breakers creates complete mini-starter assemblies sharing a single compact footprint for individual motor circuits from 0.1 kW to 11 kW.
Industrial Applications in Saudi Arabia
- Multi-axis conveyor and sorting machine motor switching in Saudi Arabia logistics and distribution centres, where dozens of individual 0.75–5.5 kW conveyor zone motors each require a compact, low-cost contactor.
- Fan coil unit individual room motor switching in hotel and commercial building fan coil unit controllers across Riyadh, Makkah, and Jeddah, where space constraints in ceiling-mounted FCU panels demand the 32 mm mini format.
- Packaging line auxiliary motor switching for labelling heads, reject mechanisms, and infeed conveyors in Saudi food and beverage manufacturing, where space in the machine control cabinet is minimised for transport.
- Pump and valve actuator motor switching in water treatment skid control panels, where the compact TeSys K fits in the limited panel space of skid-mounted equipment packages.
- Building services pump motor switching for small circulating pumps in heating, cooling, and domestic water systems in residential compounds and commercial buildings across the Kingdom.
- Lighting control contactors in commercial and industrial building distribution boards, where TeSys K handles single-phase resistive switching at AC-1 utilisation category for zone lighting circuits.
- OEM machinery electrical panel auxiliary relay and small motor switching for tool change, clamping, and indexing mechanisms in Saudi manufacturing equipment, where the compact format reduces machine panel weight.
Industrial Supplier in Saudi Arabia
Get a Quote for the Schneider Electric TeSys K Mini Contactor
We respond within 4 business hours. Send model LC1K0610M7 for competitive pricing in SAR with delivery across Saudi Arabia and the GCC.
Frequently Asked Questions — LC1K0610M7
Common questions from buyers in Saudi Arabia and the GCC
What is the Schneider Electric TeSys K Mini Contactor (LC1K0610M7) and what is it used for?
The Schneider Electric TeSys K is a miniature contactor covering 6 A to 25 A for small three-phase and single-phase motor and load switching applications on supply voltages up to 690 V AC, offering a compact and cost-effective solution for multi-motor machine control cabinets, small DOL starters, and auxiliary load switching where the TeSys D series would over-specify and over-price the application. The LC1K series occupies only 32 mm DIN rail width in the smallest frame — significantly narrower than the 45 mm minimum of TeSys D — enabling higher motor circuit density in space-constrained machine panels and providing a meaningful cost reduction per axis in multi-drive machine applications.
Where can I buy the Schneider Electric LC1K0610M7 in Saudi Arabia?
Razz Middle East supplies genuine Schneider Electric products including the Schneider Electric TeSys K Mini Contactor (LC1K0610M7) across all regions of Saudi Arabia — Riyadh, Jeddah, Dammam, Al Khobar, Jubail, Yanbu, Mecca, and Medina. We maintain local stock on fast-moving items and can source specialist configurations. Request a quote on this page for same-day pricing.
How do I get the best price for the LC1K0610M7 in KSA?
Click "Request Free Quote" on this page or message us the model number LC1K0610M7 on WhatsApp. Our technical sales team responds within 4 business hours with a competitive price in SAR, confirmed stock availability, and delivery lead time — with no hidden charges or handling fees.
Is Razz Middle East an authorized Schneider Electric supplier in Saudi Arabia?
Razz Middle East is a specialist industrial equipment supplier in Saudi Arabia focused on Schneider Electric and other leading global brands. We supply 100% genuine OEM products backed by full manufacturer warranty, serving the oil & gas, petrochemical, power generation, water, construction, and manufacturing sectors across the Kingdom.
What is the delivery lead time for the Schneider Electric TeSys K Mini Contactor in Saudi Arabia?
In-stock items typically ship within 24-48 hours to Riyadh, Dammam, Jeddah, and the Eastern Province. Project orders and non-standard configurations generally take 2-6 weeks. Contact us with the exact model number LC1K0610M7 for a precise availability confirmation and delivery date.
Can the LC1K0610M7 be supplied for ARAMCO, SABIC, or NEOM projects in KSA?
Yes. Razz Middle East has experience supplying Schneider Electric equipment to major industrial projects and EPC contractors across Saudi Arabia. We can provide full technical documentation, Material Inspection Reports (MIR), and certificates of conformity to meet vendor approval requirements. Contact our project team to discuss your specific project requirements.
