Image for illustration purposes only. Actual product may vary in appearance.
WIKA
WIKA 212.20 Pressure Gauge NS100 0-1000 bar
Model: 212.20P/N: 212.20 100mm 0-1000 bar
4-hour response · Pricing in SAR · Delivery across all KSA regions
WIKA 212.20 Pressure Gauge NS100 0-1000 bar
The WIKA 212.20 Pressure Gauge NS100 0-1000 bar is part of WIKA's pressure gauge range, described in WIKA datasheet PM 02.01. Bourdon tube pressure gauge — Stainless steel case, NS 100 [4"] and 160 [6"].
This variant is supplied with a nominal case size of NS 100 mm, a scale range of 0-1000 bar, a 1/2 NPT process connection. Approximate weight is 0.6 kg. Other ranges, connections and case sizes in this family can be configured to order — send the required specification with your enquiry.
Typical applications: For industrial applications requiring high accuracy and good readability of dial and pointer, also at a distance; For gaseous or liquid media that are suitable to the wetted parts material of the measuring element; For media that is not highly viscous and not crystallising.
Key features: Durable and robust design; Cost-effective and reliable; DNV approval for shipbuilding; Scale ranges from 0 … 0.6 to 0 … 1,000 bar [0 ... 10 to 0 ... 15,000 psi] and vacuum and compound scale ranges Bourdon tube pressure gauge, model 212.20.
Full technical data is published in WIKA datasheet PM 02.01.
Across Saudi Arabia these instruments are specified on Aramco, SABIC, Ma'aden and SWCC projects, in refinery and petrochemical service, water treatment, power generation and general plant utilities, where instrument reliability at 50 °C ambient is the deciding factor.
Razz Middle East supplies 212.20 and the wider WIKA measurement range across Saudi Arabia, sourced to order and delivered duty-paid to Jubail, Dammam, Riyadh, Jeddah and Yanbu. Quotations are answered within four working hours with SAR pricing, lead time and documentation.
Weights, dimensions and specifications shown are indicative, compiled from published WIKA data, and may vary by configuration or datasheet revision. Please confirm against the current WIKA datasheet before ordering.
Technical Specifications
Full specifications for the 212.20
- Model
- 212.20
- WIKA datasheet
- PM 02.01
- Nominal size
- NS 100 mm
- Scale range
- 0-1000 bar
- Process connection
- 1/2 NPT, G ¼ B, G ½ B, G ⅜ B
- Approx. dimensions (mm)
- h 80, S3 13, e 17, a 15.5, b1 49.5, D 101.1, SW 22
- Approx. weight
- 0.6 kg
Accuracy class ■ EN 837-1 Class 1.0
Key Features & Benefits
- Durable and robust design
- Cost-effective and reliable
- DNV approval for shipbuilding
- Scale ranges from 0 … 0.6 to 0 … 1,000 bar [0 ... 10 to 0 ... 15,000 psi] and vacuum and compound scale ranges Bourdon tube pressure gauge, model 212.20
Industrial Applications in Saudi Arabia
- For industrial applications requiring high accuracy and good readability of dial and pointer, also at a distance
- For gaseous or liquid media that are suitable to the wetted parts material of the measuring element
- For media that is not highly viscous and not crystallising
Industrial Supplier in Saudi Arabia
Get a Quote for the WIKA 212.20 Pressure Gauge NS100 0-1000 bar
We respond within 4 business hours. Send model 212.20 for competitive pricing in SAR with delivery across Saudi Arabia and the GCC.
Frequently Asked Questions — 212.20
Common questions from buyers in Saudi Arabia and the GCC
What is the WIKA 212.20 Pressure Gauge NS100 0-1000 bar (212.20) and what is it used for?
The WIKA 212.20 Pressure Gauge NS100 0-1000 bar is part of WIKA's pressure gauge range, described in WIKA datasheet PM 02.01. Bourdon tube pressure gauge — Stainless steel case, NS 100 [4"] and 160 [6"].
Where can I buy the WIKA 212.20 in Saudi Arabia?
Razz Middle East supplies genuine WIKA products including the WIKA 212.20 Pressure Gauge NS100 0-1000 bar (212.20) across all regions of Saudi Arabia — Riyadh, Jeddah, Dammam, Al Khobar, Jubail, Yanbu, Mecca, and Medina. We source fast-moving items to order and can source specialist configurations. Request a quote on this page for same-day pricing.
How do I get the best price for the 212.20 in KSA?
Click "Request Free Quote" on this page or message us the model number 212.20 on WhatsApp. Our technical sales team responds within 4 business hours with a competitive price in SAR, confirmed availability and delivery lead time — with no hidden charges or handling fees.
Is Razz Middle East an authorized WIKA supplier in Saudi Arabia?
Razz Middle East is a specialist industrial equipment supplier in Saudi Arabia focused on WIKA and other leading global brands. We supply 100% genuine OEM products backed by full manufacturer warranty, serving the oil & gas, petrochemical, power generation, water, construction, and manufacturing sectors across the Kingdom.
What is the delivery lead time for the WIKA 212.20 Pressure Gauge NS100 0-1000 bar in Saudi Arabia?
In-stock items typically ship within 24-48 hours to Riyadh, Dammam, Jeddah, and the Eastern Province. Project orders and non-standard configurations generally take 2-6 weeks. Contact us with the exact model number 212.20 for a precise availability confirmation and delivery date.
Can the 212.20 be supplied for ARAMCO, SABIC, or NEOM projects in KSA?
Yes. Razz Middle East has experience supplying WIKA equipment to major industrial projects and EPC contractors across Saudi Arabia. We can provide full technical documentation, Material Inspection Reports (MIR), and certificates of conformity to meet vendor approval requirements. Contact our project team to discuss your specific project requirements.
